- Page 1 DewStop ® breeze easy model # F100-1W Installation Guide Read and Save These Instructions LISTED Questions, Problems, Missing Parts? Please Call 1-360-876-2974 or E-Mail info@DewStop.com please retain this manual for reference...
- Page 3 SECTION 1 Ventilation Fan...
-
Page 4: Safety Information
Safety Information 1.) WARNING - TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: a) Installation work and electrical wiring must be done by qualified person(s) in accordance with all applicable codes and standards, including fire-rated construction. b) Sufficient air is needed for proper combustion and exhausting of gases through the flue (chimney) of fuel burning equipment to prevent back drafting. - Page 5 Safety Information (continued) NOTE: Make sure duct work size is a minimum WARNING: Not suitable for use as a range of the discharge. Do not reduce. Reducing the hood. duct size can increase fan noise. CAUTION: For general ventilating use only. IMPORTANT: You may want to consult with a Do not use to exhaust hazardous or professional electrician regarding the wiring of...
-
Page 6: Fan Components
Fan Components Part Description Quantity Fan body Installation bracket IV Installation bracket II Installation bracket I Installation bracket III Grille Long wood screws Short screw (4X12) Short screw (4X6) -
Page 7: Pre-Installation
Pre-Installation PLANNING FOR SUCCESSFUL Do not install ventilation fan in areas where the duct work will require configuration as shown. INSTALLATION When installing the ventilation fan in a new construction site, install the main body of the fan Turning angle too sharp Avoid duct shrink and duct work during the rough-in construction of the building. -
Page 8: Installation
Installation Determine joist width □ Measure the distance from the centre of the two □ ceiling joists where you will be installing the □ ventilation fan. □ Use the table to determine the header bar installation. □ For configuration 1, proceed to step 2. □... - Page 9 Installation (continued) Configuration 3, preparation Configuration 3, initial install □ □ Connect bracket I (D) to bracket II (C) using two Use long wood screws (BB) to loosely attach the □ □ M4x6 screws (CC). main body of fan (A) to the ceiling joist in the four □...
- Page 10 Installation (continued) Connect duct □ Install a circular duct to outlet and secure it with duct tape or clamps. □ Install the duct (G) to the outlet with a gradient 1°~2° to the outside □ as shown. □ The ducting from this fan to the outside of the building has a strong □...
- Page 11 Installation (continued) Connect wiring Attach grille □ Insert the mounting springs into the slots in the □ grille (F). WARNING: Wiring must comply with all □ Squeeze springs together and insert into the applicable electrical codes. Turn OFF power □ main body.
-
Page 12: Troubleshooting
Troubleshooting CAUTION: Do not install in locations where the temperature will exceed 40°C. Problem Possible Cause Corrective Action □ □ Fan will not turn on Power off Make sure the power supply is on □ □ Faulty switch Test or replace the switch □... - Page 13 SECTION 2 Fan Control...
- Page 14 Safety Information 1. Use only a 120V AC 60Hz power supply connection. 2. For indoor use only. 3. Do not exceed the control’s maximum electrical load ratings, as indicated on the product label. 4. Must be installed and used in accordance with your local electrical codes. 5.
- Page 15 Installation FIGURE #1 1. WARNING To avoid fire or risk of electrical shock, turn OFF power at circuit breaker or disconnect fuse. Test the power is OFF before you begin wiring. 2. BEFORE YOU MOUNT THE CONTROL (new installation) Install CONTROL the control in a 8.9 cm deep single-gang or multi-gang electrical wall enclosure.
-
Page 16: Using The Control
Using The Control FIGURE #4 Control Functions (see FIGURE #4) Blue LED Light: Lets you know when your fan is on (especially useful for fans with low sound levels). BLUE LED LIGHT Condensation Sensor: Senses moisture in the room and turns CONDENSATION SENSOR your fan ON and OFF automatically. -
Page 17: Testing The Control
Testing The Control 1. After you have completely installed the control, selected your timer and sensor settings, and attached the wall plate on the control, you can turn on the breaker to apply power. WARNING: If the breaker trips or the fuse blows, STOP and call a qualified electrician to investigate the problem. -
Page 19: Warranty
SECTION 3 WARRANTY... -
Page 20: Three-Year Limited Warranty
This warranty supersedes all prior warranties. To qualify for warranty service, you must (a) notify GTR via our website at www.DewStop.com, (b) give the model number and part number identification, and (c) describe the nature or any defect in the product or part.
