Ryobi 704rVP Parts List

3
4
35
5
3
8
1
9
2
10
Item Part No. Description
1 791-182059 Air Cleaner/Muffler Cover Assembly
(includes 2 & 35)
2 791-180350B Air Cleaner Filter
3 791-180351 Carburetor Mounting Screw Assembly
4 791-180226 Wavey Washer
5 791-182070 Choke Knob and Screw
6 753-04418 Choke Lever Assembly (includes 5)
7 753-04419 Choke Lever and Plate (includes 6)
8 753-04408 Carburetor Assembly (includes 9 & 20)
9 791-610675 Carburetor Gasket
10 791-181860 Carb Mount Screw
11 791-683974B Primer and Hose Assembly
12 753-1196 Carb Mount Assembly (includes 10, 13 & 14)
13 791-684451 Reed Assembly
14 753-1208 Carburetor Mount Gasket
15 753-04321 Crank Case Service Assembly
(includes 10)
16 791-612134 Rear Mounting Pad
17 753-04311 Fuel Tank Assembly (includes 18-20)
18 791-182438 Fuel Cap Assembly
19 791-181086 Fuel Return Line
20 791-682039 Fuel Line Assembly
21 791-145308 Front Mounting Pad
22 753-04702 Shroud Extension and Stand (includes 35)
23 791-182736 Flywheel Assembly
24 791-610303 Spacer
25 753-1199 Recoil Pulley Assembly
26 791-613102 Recoil Spring
27 791-611061 Rope Guide
28 791-181441 Pulley Retainer Assembly
29 791-181442 Switch Assembly (includes 37)
30 791-181079 Pull Handle
16
6
7
11
13
12
14
15
46
49
40
41
42 45
43
44
ENGINE PARTS - MODEL 704rVP
17
18
20
21
19
50
23
48
47
38
39
37
29
Item Part No.
31 791-613103
32 791-181443
33 791-181862
34 791-182797
35 791-181345
36 791-182519
37 791-180036
38 753-04324
39 791-610311
40 753-04618
41 753-04620
42 753-04690
43 753-04691
44 753-04315
45 753-04619
46 753-04620
47 753-04323
48 753-04367
49 753-1197
50 791-182723
* 753-1209
* 753-04322
* Items Not Shown
2-CYCLE GAS TRIMMER
PPN 41AD7V4G734
35
36
34
35
25
24
29
26
27
28
32
22
Description
Rope
Starter Housing Assembly
(includes 25-31, 33 and 34)
Housing Screw
Clutch Cover Assembly (includes 35 & 36)
Cover Screw
Anti-Rotation Screw
Wire Lead
Module Assembly
Spark Plug
Muffler Assembly (includes 41-46)
Spark Arrestor Screen
Spark Arrestor Plate
Spark Arrestor Hood
Spark Arrestor Screws
Exhaust Gasket
Muffler Mounting Bolt
Cylinder Assembly (includes 48 & 49)
Piston and Rod Assembly
Cylinder Gasket
Cylinder Bolt
Piston Ring
Short Block Assembly
(includes 10, 15, 39, 47-50)
35
30
31
29
33
35
Issued 8/04
