3
36
4
5
6
3
8
9
10
1
2
Item Part No.
Description
1
791-182059
Air Cleaner/Muffler Cover Assembly
(includes 2 & 36)
2
791-180350B Air Cleaner Filter
3
791-180351
Carburetor Mounting Screw Assembly
4
791-180226
Wavey Washer
5
753-04418
Choke Lever Assembly (includes 6)
6
791-182202
Choke Knob and Screw
7
753-04419
Choke Lever and Plate (includes 5 & 6)
8
753-04144
Carburetor Assembly (includes 9 & 20)
9
791-610675
Carburetor Gasket
10
791-181860
Carb Mount Screw
11
791-683974B Primer and Hose Assembly
12
753-1196
Carb Mount Assembly (includes 10 & 14)
13
791-684451
Reed Assembly
14
753-1208
Carburetor Mount Gasket
15
753-04272
Crank Case Service Assembly
(includes 10 & 23)
16
791-612134
Rear Mounting Pad
17
791-182767
Fuel Tank Assembly (includes 18-20)
18
791-182612
Fuel Cap Assembly
19
791-181168
Fuel Return Line
20
791-682039
Fuel Line Assembly
21
791-145308
Front Mounting Pad
22
791-153520
Shroud Assembly (includes 23)
23
791-181861
Shroud Screw
24
791-182064
Shroud Extension & Stand (includes 36)
25
791-182736
Flywheel Assembly
26
791-610303
Square Nut Drive
27
753-04232
Recoil Pulley Assembly
28
791-613102
Recoil Spring
29
791-611061
Rope Guide
16
7
11
13
12
14
15
45
43
48
46
42
41
40
ENGINE PARTS - MODEL 700rVP
2-CYCLE GAS TRIMMER
18
17
20
21
47
19
22
25
23
44
39
38
31
Item Part No.
30
791-181889
31
791-180035
32
791-181079
33
791-613103
34
791-181927
35
791-181862
36
791-181345
37
791-153597
38
791-180036
39
753-04125
40
791-610311B Spark Plug
41
753-04159
42
791-182066
43
791-147575
44
753-04323
45
753-04367
46
753-1197
47
791-182723
48
791-182747
*
753-04134
*
791-180602
*
791-181069
*
753-1209
*
753-04173
*
Items Not Shown
PPN- 41AD7VPG034
26
27
31
29
30
28
24
36
34
Description
Pulley Retainer Assembly
Switch Assembly (includes 38)
Pull Handle
Rope
Starter Housing Assembly
(includes 27-33)
Housing Screw
Cover Screw
Upper Clamp Assembly
Wire Lead
Module Assembly
Exhaust Gasket
Muffler Assembly (includes 41, 43 & 48)
Muffler Mounting Bolt Assembly
Cylinder Assembly (includes 46 & 47)
Piston and Rod Assembly
Cylinder Gasket
Cylinder Bolt
Spark Arrestor Screen
Engine Gasket Kit
O.E.M. Carburetor Repair Kit (Zama)
Gasket Diaphragm Repair Kit (Zama)
Piston Ring
Short Block Assembly
(includes 10, 15, 40, 44-47)
Issued 7/03
32
33
35
37
