MTD 240 Operator's Manual

Single-stage snow thrower
Hide thumbs Also See for 240:

Advertisement

Quick Links

Safety • Set-Up • Operation • Adjustments • Maintenance • Troubleshooting • Parts Lists • Warranty
OPERATOR'S MANUAL
READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATION
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-
covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester
for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland,
Ohio 44136-0019.
For Canadian Customers: MTD Products Ltd., P.O. BOX 1386, KITCHENER, ONTARIO N2G 4J1
PRINTED IN U.S.A.
Single-Stage Snow Thrower
For US Customers: MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019
IMPORTANT
Model 230, S230
Model 240, S240
Model 250, S250
Model 260, S260
Model 261, S261
FORM NO. 769-00805D
07/12/07

Advertisement

Table of Contents
loading

Summary of Contents for MTD 240

  • Page 1 P.O. Box 361131 Cleveland, Ohio 44136-0019. For US Customers: MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 For Canadian Customers: MTD Products Ltd., P.O. BOX 1386, KITCHENER, ONTARIO N2G 4J1 PRINTED IN U.S.A. IMPORTANT...
  • Page 2: Table Of Contents

    This Operator’s Manual is an important part of your new snow thrower. It will help you assemble, prepare and maintain the unit for best performance. Please read and understand what it says. Safety Labels ... 3 Safe Operation Practices ... 4 Set Up &...
  • Page 3: Safety Labels

    FOR TURNING, NOT LIFTING POUR TOURNER, Safety PAS POUR LE LEVAGE Labels WARNING This symbol points out important safety instructions which, if not followed, could endanger the personal safety and/or property of yourself and others. Read and follow all instructions in this manual before at- tempting to operate this machine.
  • Page 4: Safe Operation Practices

    DANGER: This machine was built to be operated according to the safe operation practices in this manual. As with any type of power equipment, carelessness or error on the part of the operator can Safe result in serious injury. This machine is capable of amputating hands and feet and throwing objects. Failure to observe the following safety instructions could result in serious injury or death.
  • Page 5 Operation 1. Do not put hands or feet near rotating parts, in the auger/impeller housing or chute assembly. Contact with the rotating parts can amputate hands and feet. 2. The auger/impeller control lever is a safety device. Never bypass its operation. Doing so makes the machine unsafe and may cause personal injury.
  • Page 6: Set Up & Adjustment

    Setup And Adjustment NOTE: This Operator’s Manual covers several models. Snow thrower features vary by model. Not all features discussed in this manual are applicable to all snow thrower models. NOTE: All references to left or right side of the snow thrower is from the operating position only.
  • Page 7: Know Your Snow Thrower

    Electric Starter Button Figure 4A Fuel Cap Chute Assembly Shave Plate Auger IMPORTANT: This unit runs on a mixture of gasoline and oil. Do NOT operate the snow thrower without first reading the engines operator’s manual for instructions regarding proper fuel and engine oil. Choke Lever Activating choke control closes the choke plate on carburetor and aids in starting engine.
  • Page 8: Operation

    Before Starting Operation 1. The spark plug wire was disconnected for safety. Attach spark plug wire to spark plug before starting. IMPORTANT: For complete and detailed engine starting, stopping and storing instructions, it is recom- mended that you read the engine manual also included with this unit.
  • Page 9: To Stop Engine

    7. As engine warms up and begins to operate evenly, rotate choke lever slowly to the 1/2 Choke position. When the engine begins to run smoothly, move the choke to the OFF position. If engine falters, return to FULL choke, then slowly move to 1/2 then OFF position.
  • Page 10: Adjustments & Maintenance

    Adjustments & Maintenance WARNING Disconnect the spark plug wire and ground it against the engine to prevent unintended starting. NEVER attempt to make any adjust- ments while the engine is run- ning, except where specified in the operator’s manual. Before servicing, repairing, or inspect- ing, disengage the control bail and...
  • Page 11: Replacing Belt

    Replacing Belt WARNING: Before servicing, repairing, or inspecting, disengage the control bail and stop engine. Wait until all moving parts have come to a complete stop. Disconnect spark plug wire and ground it against the engine to prevent unintended starting. Remove the belt cover by removing five hex screws.
  • Page 12: Off-Season Storage

    Observe the following, when preparing your snow thrower for off-season storage: • Drain fuel into an approved container outdoors, away from any open flame. Allow engine to cool. Extin- guish cigarettes, cigars, pipes and other sources of ignition prior to draining fuel. Fuel left in engine Off-Season during warm weather deteriorates and will cause serious starting problems.
  • Page 13: Trouble Shooting

    Problem 1. Choke not in ON position. Engine fails to start 2. Spark plug wire disconnected. 3. Fuel tank empty or stale fuel. 4. Engine not primed. 5. Faulty spark plug. 6. Blocked fuel line. 7. Safety key not in ignition on engine. 8.
  • Page 14: Illustrated Parts Lists

    Models/Modèles 230-260...
  • Page 15 Models/Modèles 230-260 PART N° DE N° DE RÉF PIÈCE DE SCRIP TION 629-0236 Cord-Extension 110V3M 2 Prong 710-0627 Hex L-Bolt 5/16-24 x .75 Gr. 5 710-1003 Hex Wash B-Tapp Scr #10 x .62" Lg. 710-0805 Screw-Hex Cap 5/16-18 x 1.5 Gr. 5 710-3025 Screw-Hex Cap 5/16-18 x .625 Gr.
  • Page 16 Models/Modèles 230-260 �� �� �� �� �� �� �� � � � � � �� �� � � �� �� �� �� �� �� � �� �� � � �� �� �� �� �� �� �� �� �� ��...
  • Page 17 Models/Modèles 230-260 PART N° DE N° DE RÉF PIÈCE DE SCRIP TION 684-04127 Lower Chute Ass’y (Incl. #5-7 and 10) 710-04071 Carriage Screw 5/16-18 x 1.0 710-0451 Carriage Bolt 5/16-18 x .75 712-04063 Flange Locknut 5/16-18 Gr. F, Ny lon 720-0284 Han dle Knob As sem bly 731-04388A...
  • Page 18: Warranty

    The limited warranty set forth below is given by MTD LLC with respect to new merchandise purchased and used in the United States and/or its territories and possessions, and by MTD Products Limited with respect to new merchandise purchased and used in Canada and/or its territories and possessions (either entity respectively, “MTD”).

This manual is also suitable for:
