• The controllers of the onboard LAN and LAN cards are as follows:
LAN cards
Onboard LAN (1000BASE-T)
PG-1852
PG-1862
PG-1882L/PG-1892L
5.6.2 Cautions for Onboard/PG-1852/1862/188x/189xLAN
Driver V8.3
■ Event Log
Once a Team is setup, multiple identical logs from the same source that starts with the following log may
be stored in the system log file of the event viewer at system start-up.
Source iANSMiniport
ID 11
Type Warning
Description The following adapter link is not connected: (Adapter name)
* (Adapter name) varies depending on the OS or hardware configuration.
Since such event logs will be stored nonetheless even if the Teaming function is operated normally,
ignore them.

5.6.3 Teaming (AFT/ALB/SFT) Function

■ Notes
When using the Teaming function, note the following points.
• You require Service Pack 2 or later for Windows 2000 Server.
• For AFT/ALB type, you can incorporate up to four (4) LAN ports into one team, and two ports for a
SFT type team.
• Once a Team is created, virtual adapters (Intel® Advanced Network Service Virtual Adapter) will be
created in the [Device Manager] and/or [Network and Dial-up Connections] of the system. Do not
disable or delete a virtual adapter from the [Device Manager] or [Network and Dial-up Connections].
When deleting a virtual adapter, make sure to use "Intel
• When the Teaming function is being used, you can only use the following protocols:
• For AFT/SFT type: IP, NetBEUI, IPX (NCP), IPX (NetBIOS)
• For ALB type: IP, IPX (NCP)
• When the Teaming function is being used, you cannot use the hardware assist function of IPSEC. Do
not use this function even if the function is installed in all cards in the team.
table: Controller being used
Controller being used
®
Intel 82547GI
®
Intel 82540EM
®
Intel 82546EB
®
Intel 82545GM
PRIMERGY RX100 S2 User's Guide
®
PROSet".
