Chapter 4 Manual OS Installation

4.3 Installing the LAN Driver

This section explains the procedure for installing the driver.
In addition to the case where the OS is installed manually, the driver must be installed
when a LAN card is added.

4.3.1 Installing the LAN Driver (Windows Server 2003)

The LAN driver installation procedure differs depending on whether the network adapter was
recognized during the OS installation.
For the following LAN cards, the network adapter is recognized when the card is mounted during OS
installation.
• PG-1852
• PG-1862
1
Click [Start] → [Administrative Tools] → [Computer Management].
2
Click [Device Manager].
On the Device Manager list, check if a recognized network adapter is present.
(Window example)
When a recognized network adapter is present, [Network adapters] appears.
120
Recognized
network adapter
Unrecognized
network adapter
