Product Overview
7
Dimensions
1.7 Dimensions
Figure 1-5. Unit Dimensions—Front and Side View
Figure 1-6. Unit Dimensions—Rear View and Mounting Hole Locations
Dimensions are in Inches [Millimeter]
0.869 [22.07]
ø0.280 [ø7.11]
(4 Places)
ø0.854 [ø21.69]
3.380
[85.85]
1.690
[42.93]
1.690
0.869 [22.07]
[42.93]
3.380 [85.85]
Operations Guide
930796B
CyberData Corporation
