READ SAFETY RULES AND INSTRUCTIONS CAREFULLY BEFORE OPERATION
Warning: This unit is equipped with an internal combustion engine and should not be used on or near any unimproved forest-covered, brush-
covered or grass-covered land unless the engine's exhaust system is equipped with a spark arrester meeting applicable local or state laws (if any).
If a spark arrester is used, it should be maintained in effective working order by the operator. In the State of California the above is required by law
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester
for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland,
Page 1
(Section 4442 of the California Public Resources Code). Other states may have similar laws. Federal laws apply on federal lands. A spark arrester for the muffler is available through your nearest engine authorized service dealer or contact the service department, P.O. Box 361131 Cleveland, Ohio 44136-0019. FORM NO. 769-02298B PRINTED IN U.S.A. MTD LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019 10/12/2006...
Trouble Shooting ... 12 Off Season Storage and Safety Labels ... 13 MTD LLC reserves the right to change product specifications, designs, and equipment without notice and without incurring obligation. Finding and Recording Model Number BEFORE YOU BEGIN TO ASSEMBLE YOUR NEW...
Use this page as a guide to determine slopes where you may not operate safely. Do not operate your lawn mower on such slopes. Slope Gauge WARNING Do not mow on inclines with a slope in excess of 15 degrees (a rise...
DANGER: This machine was built to be operated according to the rules for safe operation in this manual. As with any type of power equipment, carelessness or error on the part of the operator Safe can result in serious injury. This machine is capable of amputating hands and feet and throwing objects.
19. Shut the engine off and wait until the blade comes to a complete stop before removing the grass catcher or unclog- ging the chute. The cutting blade continues to rotate for a few seconds after the engine is shut off. Never place any part of the body in the blade area until you are sure the blade has stopped rotating.
Setup and Adjustment WARNING The chute retainer must be removed and discarded before operating the mower. NOTE: Your mower is shipped with the handle in the higher height position. NOTE: Each end of the lower handle must be placed in the same relative position. NOTE: This Operator’s Manual covers several models. Lawn Mower features vary by model. Not all features discussed (or engines pictured) in this manual are applicable to all Lawn Mower models. Figure 3-1 Figure 3-2 Figure 3-3 1. For shipping purposes, the chute deflector on your mower is held in an upright position by a retainer. Remove the retainer as follows: a. Push chute deflector up towards engine. Holding deflector in this position, remove the retainer and discard. See Figure 3-1. b. Lower the chute deflector carefully keeping your fingers out of the way.
Page 7
5. Rope guide Setup as follows in Figure 3-5: a. Hold the blade control against the upper handle. b. Slowly pull starter rope out of engine. c. Slip starter rope into the rope guide. d. Tighten rope guide wing nut. 6. Each wheel has a height adjustment lever to change the cutting height of the mower. a. Depress height adjustment lever towards wheel. b. Slide lever to desired position for a change in cutting height. See Figure 3-6. c. Release lever towards deck. 7. Install mulching baffle on the right side of the mower following the steps below: a. Lift up and hold the side-discharge chute deflector and insert bottom lip of the mulching baffle inside the chute opening See Figure 3-7. b. Snap hooks of the mulching baffle over the hinge pin of the chute deflector. The hooks must snap into place on the hinge pin, locking the mulching baffle firmly onto mower. Release chute deflector. Figure 3-5 Figure 3- Figure 3- Setup and Adjustment CUTTING HEIGHT All wheels must be...
Never attempt to bypass its Now that you have set up your lawn mower for opera- operations. tion, get aquainted with its controls and features. These are described below and illustrated on this page. This...
Figure 4-2 Be sure lawn is clear of stones, sticks, wire, or other objects which could damage lawn mower or engine. Such objects could be accidently thrown by the mower in any direction and cause serious personal injury to the operator and others.
General Recommendations 1. Always observe safety rules when performing any maintenance. Always stop engine, 2. The warranty on this lawn mower does not cover disconnect spark items that have been subjected to operator abuse plug, and ground or negligence. To receive full value from warranty,...
Blade Care WARNING: When removing cutting blade for sharpening or replacement, protect your hands with a pair of heavy gloves or use a heavy rag to hold blade. 1. Disconnect spark plug boot from spark plug. Turn mower on its side making sure that the air filter and the carburetor are up.
2. Connect wire to spark plug. 3. Fill tank with clean, fresh gasoline. 4. Choke engine as instructed in “Operating Your Lawn Mower”. 5. Clean, adjust gap, or replace. 6. Clean fuel line. 7. Wait a few minutes to restart.
Using a light oil or silicone, coat the equipment, especially cables and all moving parts of your lawn mower before storage. Read and follow Operating Instructions before running engine.
Engine Safe Operation Practices • When adding fuel, turn engine OFF and let engine cool at least 2 minutes before removing gas cap. • Fill fuel tank outdoors or in well ventilated area. • Use only an approved gasoline container. •...
Running engine produces heat. Engine parts, especially muffler, become extremely hot. Severe thermal burns can occur on contact. Combustible debris, such as leaves, grass, brush, etc., can catch fire. • Allow muffler, engine cylinder, and fins to cool before touching. •...
IMPORTANT: This engine is shipped Read this section before starting your lawn mower engine. Compare the illustrations in Figure 9-1 with your lawn without gasoline or oil mower engine to familiarize yourself with the location of various controls and adjustments.
Check Oil Level IMPORTANT: Be sure to check the engine on a level surface with the engine stopped. 1. Remove the oil filler cap and wipe the dipstick clean. See Figure 9-2. 2. Insert the dipstick into the oil filler neck, but do not screw it in.
IMPORTANT: If engine must be tipped to transport equipment or to inspect or remove grass, keep spark Maintaining plug side of engine up. Transporting or tipping engine spark plug down may cause smoking, hard starting, Your spark plug fouling, or oil saturation of air cleaner. Engine Tasks Check Engine...
IMPORTANT: Used motor oil may cause skin cancer if repeatedly left in contact with the skin for prolonged periods. Although this is unlikely unless you handle used oil on a daily basis, it is still advisable to thoroughly wash your hands with soap and water as soon as possible after handling used oil.
Electrode Maintaining Your Engine Figure 10-4: Measure the plug gap with a feeler gauge. 3. Measure the plug gap with a feeler gauge. Correct as necessary by bending side electrode. See Figure 10-4. The gap should be set to 0.030 in. 4.
MTD LLC (MTD), The United States Environment Protection Agency (U. S. EPA) The U. S. EPA and MTD are pleased to explain the emissions control system warranty on your model year 2005 and later small off-road engine. New small off-road engines must be designed, built and equipped to meet the stringent anti-smog standards. MTD must warranty the emission control system on your engine for the period of time listed below, provided there has been no abuse, neglect or improper maintenance of your small off-road engine.
Page 27
(c) MTD will include a copy of the following emission warranty parts list with each new engine, using those portions of the list applicable to the engine.
Page 28
MANUFACTURER’S LIMITED WARRANTY FOR The limited warranty set forth below is given by MTD LLC with respect to new merchandise purchased and used in the United States, its posses- sions and territories. “MTD” warrants this product against defects in material and workmanship...
