HANDSET CONTROLS AND FUNCTIONS
TALK/BATT.LOW LED
PAUSE Button
One-touch dialing Button
( MEM1 - MEM3 )
Rechargeable Battery Pac
(back)

BASE UNIT CONTROLS AND FUNCTIONS

DC 9V IN Jack
TEL Line Jac
TONE Button
RDL (Redial) Button
HOLD Button
IN USE LED
CHARGE LED
POWER LED

OPERATING CONTROLS

TALK Button
TONE Button
MEM Button
Antenna
REDIAL Button
FLASH Button
Dialpad
VOL/RING Button
CH Button
MUTE Button
Charging Contact
2
TONE/PULSE Switch
Line Ringer Volume Switch
Speaker
Antenna
MEM (Memory) Button
Speed Dial Index (1 to 10)
PAUSE Button
MUTE Button
INTCOM LED (Green)
Speaker Volume Control
INTCOM Button
FLASH Button
Speaker LED (Green)
SPEAKER Button
Microphone
