marsden Boxer MPS 30 Operator's Manual

The Boxer
INTRODUCTION
All scales come complete with an easy to clean stainless steel top on a study steel frame, and a
remote indicator with a large LCD display which is easy to read from a distance.
The water-resistant keyboard has 4 easy to use function keys: NET/GROSS -UNIT-ON/OFF-TARE.
With the standard AC adapter included and the facility for dry cell batteries, the scales can be used in
a fixed location or as a portable scale.
ASSEMBLY
The scale comes complete with the stainless steel top and a power supply module.
Plug the power supply into the socket on the left side of the weight indicator. Then plug the power
supply into the mains power.
The scale can also be used with batteries for a truly portable scale
Installing batteries
Power can be supplied by mains adapters delivering a regulated 6 to 15VDC 100 mA , or using
batteries inside of scale's head (6 x AA Size). Remove the cover from the battery compartment
under the stainless steel pan by lifting the tab.
It is suggested Alkaline batteries be used for best life.

SPECIFICATIONS

Model #
Maximum Capacity
Readability
Resolution
Tare Range
Repeatability (Std Dev)
Linearity ±
Units of Measure
Stabilisation Time
Operating Temperature
Power supply
Calibration
Calibration mass
Indicator display
Platform Size
Dimensions (w x d x h)
Gross Weight
OPERATOR'S MANUAL
Install six AA size batteries as shown:
MPS 30
30 kg
0.01 kg
1:3000
Full range Full range
+/- 1d
+/- 2d
5°C - 35°C or 13 F - 95°F
6 x AA batteries or 9V-15V 100ma AC adapter
20 kg
26mm/1.0" LCD digital display showing
net, gross, zero, stable and weighing units
310 x 300 mm / 12¼ x 12"
Base: 310 x 300 x 50 mm
Indicator: 270 x 80 x 30mm
6 X "AA" Alkaline
MPS 60
60 kg
0.02 kg
1:3000
+/- 1 d
+/-2d
Kg/lb/oz
1-2 secs.
Automatic External
40 kg
12 ¼ x 12 x 2"
11 x 3 x 1"
4.8 Kg / 10.6 lb.
MPS 150
150 kg
0.05 kg
1:3000
Full range
+/- 1d
+/- 2d
100 kg
