Type of product
Date of purchase
Name
Address
15
ROYAL Reverse Osmosis Drinking Water Systems
Memo
Tel
URE
DRINKING WATER SYSTEM
URE
DRINKING WATER SYSTEM
REVERSE OSMOSIS SYSTEM
RS-106M
USER'S MANUAL
01
Introduction of RS-106M
02
What is reverse osmosis
03
Components & Selected filters
04
Cartridge filters
05
The parts of RS-106M
06
Tubing connection diagram
07
Installation diagram
08
Change filters
09
Change membrane
10
Operation regulation
12
The functions of Mineral Filter
13
FAQ
14
Maintenance checking list
15
Memo
Thank you very much for selecting Pure-Pro Water Corp.
In order to bring the best use of your system, please read
the user's manual carefully before installation and follow
the regulations.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PurePro RS-106M
Summary of Contents for PurePro RS-106M
- Page 1 Address RS-106M USER'S MANUAL Introduction of RS-106M What is reverse osmosis Components & Selected filters Cartridge filters The parts of RS-106M Tubing connection diagram Installation diagram Change filters Change membrane Operation regulation The functions of Mineral Filter Maintenance checking list Memo Thank you very much for selecting Pure-Pro Water Corp.
-
Page 2: Maintenance Checking List
RO water production. This allows for better assurance that there is adequate water available when desired, even during heavy use times of the day. PurePro ROYAL RO with its supreme quality ensures a great water flow rate with absolutely the least wasting of water. -
Page 3: What Is Reverse Osmosis
Water flow Q: What does the PurePro series drinking water taste like? The taste of the PurePro water depends on the amount of contaminants in the tap water originally. If 95% of dissolved minerals and chemicals are removed, the R.O. water may taste like distilled water (no minerals), bottled water (low mineral), or natural spring water (moderate mineral content). - Page 4 Components & Selected filters The functions of Mineral Filter ¨Components The mineralized water after the Mineralized filter has perfectly balanced proportions of minerals necessary for healthy development of the human body. The Mineralized filter was designed by top specialists in The Military Medical Academy in Taiwan. This filter improves the qualities of clean water by adding necessary health minerals, such as Calcium, Magnesium, Sodium, Potassium, as well as others readily found in many natural mineral waters for proper human development.
-
Page 5: Cartridge Filters
Operation regulation Cartridge filters A.With everything connected, turn on the water check for leaks. Cartridge Filters Filter Description Service Life B.Make sure the storage tank shut-off valve is "OFF". Open the sink Stage 1 RS300ST 6 Months top faucet. With only five micron rating. It is effective in 5 Micron C.Within a few minutes (up to 15) the water will start to run from the removing dirt, rust and sand particles. - Page 6 The parts of RS-106M Operation regulation Turn on water source. Pressure gauge To RO system The 3rd stage filter The 1st stage filter Switch on water tank. The 2nd stage filter Input water To the faucet RO membrane housing Let the water run for at least 30 To the tank minutes.
-
Page 7: Change Membrane
Change membrane Tubing connection diagram CONNECTING THE COLOR TUBING: Turn off water source. Switch off water tank. A. Connect the WHITE tubing to the water supply connector. B. Connect the BLUE tubing to the sink top faucet. C. Connect the BLACK tubing to the drain saddle. D. -
Page 8: Installation Diagram
Installation diagram Change filters Input water : Install water tank : Turn off water source. Switch off water tank. Tank ball shut- off valve Water supply connector To RO system To RO system Hand tighten To RO system plastic shut-off valve to tank.
