Summary of Contents for APW Wyott IBB-05F
- Page 1 IBB-05F USER’S MANUAL Model# IBB-05F Induction Range 120Volt, 60Hz, 500watt 2013/04/22...
- Page 2 IBB-05F USE AND CARE INSTRUCTIONS – IMPORTANT SAFEGUARDS READ ALL INSTRUCTIONS BEFORE OPERATION Use an individual 120Volt electrical socket. DO NOT connect more than 3 units in the same power source if it’s connected to a 15A circuit. DO NOT block the air-intake panel; blocking it may cause overheating of the unit.
- Page 3 IBB-05F SUITABLE USTENSILS- FOR INDUCTION HEATING PLATES, SUITABLE POTS, 1. Iron 2. Cast iron 3. Stainless steel 4. Enamelware All pots and pans must have a magnetic bottom. All pots and pans must have a flat bottom. All pots and pans should have a diameter between 12cm (4 ”) and 24cm (10”).
-
Page 4: Safety Device
IBB-05F SAFETY DEVICE Automatic Safety Shut-Off, If the induction range is left on for more than 60 seconds without a pan or with an incompatible pan, the unit will automatically shut off. Material Compatibility Detector If the pan’s material or it’s dimensions are not suitable for this induction range, the “Heating”... - Page 5 IBB-05F PRECAUTION BEFORE USING YOUR INDUCTION HOB 1. In case of breakage on glass-top, even if it's only slightly cracked, disconnect the appliance from the power supply immediately and contact after-sales service. 2. The appliance is equipped with 'small object detector'. But, it's recommended not to place metal kitchen utensils, pan lids, knives, or other metal objects on the induction heating zone.
- Page 6 IBB-05F OPERATION INSTRUCTION 1. Plug power cord into 120 volt power socket. 2. Place a suitable pot/pan on center position of top plate. 3. Turn on power by pressing the on/off key, digital-display will display will light on and show “0”...
-
Page 7: Features & Description
IBB-05F FEATURES & DESCRIPTION: Table cut off size: 298 mm x 295mm Control box cut off size: 55mm (H) x 120mm (W) Air In-Take Hole: 55(H) x 160 (W) Air Out-Take Hole: 55(H) x280 (W) mm 2013/04/22... -
Page 8: Specification
IBB-05F Remarks: Keep good air intake and outlet space is very important for good quality and function for this induction cooking device. Recommend to keep a open underneath the table not smaller than 200cm (50x400mm) for fresh and cool air can be used for cooling the induction components (Air in-take hole, and air out-take hole). -
Page 9: Troubleshooting
IBB-05F TROUBLE SHOOTING 1. If your induction range seems to be working improperly, it doesn't necessarily mean it's defective. In all cases, check the following points. 2. If you fail to identify the problem, contact after-sales service without delay. If.. - Page 10 Should any product fail to function in its intended manner under normal use within the limits defined in this warranty, at the option of APW Wyott such product will be repaired or replaced by APW Wyott or its Authorized Service Agency. APW Wyott will only be responsible for charges incurred or service performed by its Authorized Service Agencies.
- Page 11 Wyott does not assume any liability for extended delays in replacing or repairing any items beyond its control. In all cases, the use of other than APW Wyott Authorized OEM Replacement Parts will void this warranty. This equipment is intended for commercial use only. Warranty is void if equipment is installed in other than commercial application.
