Quality Fireplaces for Life
DIRECT VENT FIREPLACE
WARNING
: This product must be installed by
a licensed plumber or gas fitter when installed
in the Commonwealth of Massachusetts.
IMPORTANT: Installation of a CO detector is
required in the fireplace room when installed in
the Commonwealth of Massachusetts.
WARNING:
If the information in these instructions are not followed exactly, a fire or
explosion may result, causing property damage, personal injury or loss of life.
◙
Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
IF YOU SMELL GAS:
◙ Do not light any appliance.
◙ Do not touch any electrical switch: do not use any phone in your building.
◙ Immediately call gas supplier from a neighbors phone. Follow the gas supplier instructions.
◙ If you cannot reach your gas supplier, call the fire department.
◙ Installation and service must be performed by a qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes.
This appliance is only for use with the type (s) of gas indicated on
the rating plate. A conversion kit is supplied with the appliance.
OPERATION MANUAL
INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
www.kozyheat.com
INSTALLATION
AND
April 2009
PRC-04-09-R06
Advertisement
Table of Contents
Troubleshooting
Related Manuals for kozy heat PRINCETON RPC-36
Summary of Contents for kozy heat PRINCETON RPC-36
- Page 1 INSTALLATION OPERATION MANUAL INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE. CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE. Quality Fireplaces for Life DIRECT VENT FIREPLACE WARNING : This product must be installed by a licensed plumber or gas fitter when installed in the Commonwealth of Massachusetts.
-
Page 2: Introduction And Homeowner Reference Information
Please retain this owner’s manual for future reference. CONGRATULATIONS! We welcome you as a new owner of a Kozy Heat gas fireplace. Kozy Heat products are designed with superior components and materials and assembled by trained craftsmen who take pride in their work. The burner and valve assembly are 100% test-fired and the complete fireplace is thoroughly inspected before packaging to ensure that you receive a quality product. -
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION VENTING (cont.) Introduction and Homeowner Reference Information Horizontal Min. / Max. Venting Illustrations 22-23 CONTENTS Vertical Vent System Clearances Table of Contents Vertical Termination Minimum / Maximum SAFETY INFORMATION Combustion Air Intake Settings Safety Information Horizontal / Vertical Combination Venting FEATURES Vertical Min. -
Page 4: Safety Information
SAFETY INFORMATION This fireplace has been tested to and complies with ANSI Z21.88a-2007·CSA 2.33a-2007·CSA P.4.1-02 “VENTED GAS FIREPLACE HEATERS” by OMNI-Test Laboratories, Portland, OR. Installation must conform with local building codes or in the absence of local building codes, with the National Fuel Gas Code, ANSIZ223.1/NFPA 54 - Current Edition, or the Natural or Propane Installation Code, CSAB149.1 Installation and repair should be done only by a qualified service person. -
Page 5: Features
Removable millivolt board with 30-second delay pilot Upper grill / hood & lower grill (black) Automatic pressure relief glass system Accepts rigid pipe or Kozy Heat flexible vent system Requires no electricity to operate High - Low regulator (excluding fan & light kit) -
Page 6: Commonwealth Of Massachusetts Information
COMMONWEALTH OF MASSACHUSETTS REQUIREMENTS NOTE: The following requirements reference various Massachusetts and national codes not contained in this manual. For all sidewall horizontally vented gas fueled equipment installed in every dwelling, building or structure used in whole or in part for residential purposes, including those owned or operated by the Commonwealth and where the side wall exhaust vent termination is less than (7) feet above finished grade in the area of the venting, including but not limited to decks and porches, the following requirements shall be satisfied: INSTALLATION OF CARBON MONOXIDE DETECTORS... -
Page 7: Specifications
SPECIFICATIONS " 625mm FIREPLACE DIMENSIONS " LETTER KEY 543mm DESCRIPTION Height Width Back Width Depth Opening Glass Frame Stand-off Front to Vent Floor to Vent Front to " Width Height Height Center Center Angled Back (Vert. Term.) (Hor. Term.) 260mm INCHES 35-7/8 24-5/8... -
Page 8: Clearances
SPECIFICATIONS STAND-OFF STAND-OFF FIREPLACE FRONT FIREPLACE FRONT WARNING: NON-COMBUSTIBLE ZONE: STAND-OFFS PROVIDE THE 10” (254 mm) MINIMUM CLEARANCE TO HEADER. USE LEFT SIDE RIGHT SIDE ONLY NON-COMBUSTIBLE MATERIAL IN THIS AREA FOR THE ENTIRE WIDTH OF FIREPLACE. DO NOT USE WOOD, SHEET- ROCK ETC. -
Page 9: Components List
SPECIFICATIONS MODEL #PRC-36 COMPONENTS LIST MODEL #PRC-36-RF COMPONENTS (#PRC-770) - Millivolt Board Assembly with 18” Flexible Gas (#PRC-800-RF) - Millivolt Board Assembly with 18” Flexible Line attached Gas Line attached (#700-203) - Manual Gas Shut-off Valve (#700-203) - Manual Gas Shut-off Valve (#PRC-135) - Burner / Log Grate Assembly (#PRC-135) - Burner / Log Grate Assembly (#PRC-G900) - Refractory Set... -
Page 10: Prepare The Fireplace
PREPARE THE FIREPLACE STAND-OFF ASSEMBLY & INSTALLATION CAUTION: IMPORTANT: THE TOP STAND-OFF BRACKETS MUST BE FORMED AND AT- STAND-OFF BRACKETS ARE TACHED PRIOR TO POSITIONING THE FIREPLACE INTO FRAMED OPENING. NOT LOAD BEARING. The top stand-off brackets are attached to the fireplace top in a flat state for shipping. Remove and save the (4) screws securing stand-off heat shield and stand-off brackets. -
Page 11: Horizontal Vent Heat Shield Installation
PREPARE THE FIREPLACE HORIZONTAL VENT HEAT SHIELD INSTALLATION IMPORTANT: THE HORIZONTAL VENT HEAT SHIELD MUST BE INSTALLED WHEN USING A 45-DEGREE ELBOW TO HORIZONTALLY POSITION THE VENT SYSTEM. EXCEPTION: CORNER INSTALLATIONS To Install Horizontal Vent Heat Shield: Loosen, but do not remove center three screws at the back of Attach here. -
Page 12: Framing
FRAMING WALL ENCLOSURE ROUGH OPENING IMPORTANT: Framing dimensions should allow for wall covering thickness and fireplace facing materials. If using a hearth, adjust rough opening size as necessary to maintain at least the minimum clearance requirements. IMPORTANT: NON-COMBUSTIBLE FACING MATERIAL MAY BE APPLIED OVER (BUT NOT DIRECTLY TO) FIREPLACE FACE. -
Page 13: Hearth Extension Requirements
Follow vent pipe manufacturer‟s installation instructions for horizontal terminations. Include the required 1-1/2” (38 mm) top clearance and 1” (25 mm) sides and bottom clearances for approved rigid vent systems and the Kozy Heat #800 series flexible vent system. MINIMUM HORIZONTAL FRAMING DIMENSIONS VENT PIPE TOP (A) FRAMED OPENING TOP (B) 34-3/8”... -
Page 14: Typical Installation Options
TYPICAL INSTALLATION OPTIONS IMPORTANT: KOZY HEAT WALL THIMBLE PASS-THRU (#800-WPT or #800-WPT2) MUST BE USED ON ALL HORIZONTAL VENT RUNS. FOLLOW INSTRUCTIONS ON PAGE 21 OF THIS INSTALLATION MANUAL. IMPORTANT: THE HORIZONTAL HEAT SHIELD INCLUDED WITH THIS FIREPLACE MUST BE INSTALLED WHEN USING A 45-DEGREE ELBOW DIRECTLY OFF THE TOP OF UNIT TO HORIZONTALLY POSITION THE VENT SYSTEM. -
Page 15: Mantel Requirements
MANTEL REQUIREMENTS WARNING: TOP STAND-OFF BRACKETS MUST BE ASSEMBLED AND ATTACHED TO FIREPLACE. DO NOT REMOVE. CAUTION: STAND-OFF BRACKETS ARE NOT LOAD BEARING. PAGE 14... -
Page 16: Glass Frame Assembly
GLASS FRAME ASSEMBLY REMOVE GLASS FRAME ASSEMBLY CAUTION: TO PREVENT THE GLASS FRAME ASSEMBLY FROM FALLING FROM THE FIREPLACE AND BECOMING DAMAGED, FOLLOW THESE INSTRUCTIONS EXACTLY WHEN REMOVING GLASS FRAME ASSEMBLY. A. Locate the spring-loaded handles securing glass frame assembly at the top & bottom of firebox. Pull bottom handles out and „down‟... -
Page 17: Prc-36 Only) Optional Fan Installation
OPTIONAL FAN INSTALLATION (PRC-36 only) INSTALLATION OF THIS FAN SHOULD BE DONE ONLY BY A QUALIFIED INSTALLER WARNING: MAKE SURE HOUSEHOLD BREAKER IS SHUT OFF PRIOR TO WORKING ON ANY ELECTRICAL LINES. IMPORTANT: If installing a fan, it is easier to complete before the millivolt board is connected to the gas line. -
Page 18: Fan Installation
OPTIONAL FAN INSTALLATION (PRC-36 only) Insert fans through the lower grill opening, push to the back, posi- tioning behind legs. Connect fan wiring by attaching connectors on right fan onto termi- nals on left fan. From inside the lower right grill opening, loosen screw securing removable access panel (with electrical box &... -
Page 19: Gas Line Connection
GAS LINE CONNECTION GAS CONVERSION This fireplace is manufactured for use with Natural Gas. An LP conversion kit, is included with this fireplace. Follow instructions included with the conversion kit if converting to LP gas. Model PRC-36; #OCK-S5271A Model PRC-36-RF; #OCK-H5271L-RF CAUTION: Installation of the gas line must only be ATTENTION: The conversion shall be carried out in accordance done by a qualified person in accordance with local... -
Page 20: Thermostat / Wall Switch / Remote
THERMOSTAT / WALL SWITCH / REMOTE (PRC-36 only) CAUTION: DO NOT CONNECT HIGH NOTE: INSTALLATION OF THERMOSTAT OR WALL VOLTAGE (115V) WIRE TO THE GAS SWITCH SHOULD ONLY BE DONE BY A QUALIFIED VALVE! INSTALLER. If desired, a thermostat (wireless style also available), wall switch, or remote control assembly may be used to turn the fireplace „OFF‟... -
Page 21: Approved Venting
OFF FIREPLACE TO HORIZONTALLY POSITION THE VENT SYSTEM. EXCEPTION: CORNER INSTALLATIONS THE KOZY HEAT WALL PASS-THRU, PART #800-WPT (4-1/2” (114 mm) - 6-1/2” (165 mm) ) WALL THICKNESS OR #800-WPT2 (6-1/2” (165 mm) - 12-1/2” (318 mm) ), MUST BE USED ON ALL HORIZONTAL VENT RUNS. -
Page 22: 800-Wpt Wall Pass-Thru Installation Instructions
WARNING: MAINTAIN ALL CLEARANCES AS STATED IN THIS INSTALLATION MANUAL. IMPORTANT: If using the Kozy Heat series flexible vent system, re- move the inner ring on each wall thimble section with a tin snips. This will provide adequate room for the flexible vent system. -
Page 23: Horizontal Min. / Max. Venting Illustrations
OFF FIREPLACE TO HORIZONTALLY POSITION THE VENT SYSTEM. EXCEPTION: CORNER INSTALLATIONS THE KOZY HEAT WALL PASS-THRU, PART #800-WPT (4-1/2” (114 mm) - 6-1/2” (165 mm) WALL THICKNESS) OR #800-WPT2 (6-1/2” (165 mm) - 12-1/2” (318 mm) WALL THICKNESS), MUST BE USED ON ALL HORIZONTAL VENT RUNS. - Page 24 THE KOZY HEAT WALL PASS-THRU, PART #800-WPT (4-1/2” (114 mm) - 6-1/2” (165 mm) WALL THICKNESS) OR #800-WPT2 (6-1/2” (165 mm) - 12-1/2” (318 mm) WALL THICKNESS), MUST BE USED ON ALL HORIZONTAL VENT RUNS.
-
Page 25: Vertical Vent System Clearances
OFF FIREPLACE TO HORIZONTALLY POSITION THE VENT SYSTEM. EXCEPTION: CORNER INSTALLATIONS THE KOZY HEAT WALL PASS-THRU, PART #800-WPT (4-1/2” (114 mm) - 6-1/2” (165 mm) WALL THICKNESS) OR #800-WPT2 (6-1/2” (165 mm) - 12-1/2” (318 mm) WALL THICKNESS), MUST BE USED ON ALL HORIZONTAL VENT RUNS. -
Page 26: Vertical Min. / Max. Venting Illustrations
VENTING (Vertical) VERTICAL TERMINATIONS MAXIMUM VERTICAL VENTING MINIMUM VERTICAL VENTING TERMINATION CAP TERMINATION CAP 2 ft.” (610 mm) 30 ft. (9.14 m) 45° ELBOW 45° ELBOW CAUTION: This gas appliance must not be connected to or joined with any other chimney flue serving another appliance. -
Page 27: Horizontal & Vertical Combination Venting Illustration
OFF FIREPLACE TO HORIZONTALLY POSITION THE VENT SYSTEM. EXCEPTION: CORNER INSTALLATIONS THE KOZY HEAT WALL PASS-THRU, PART #800-WPT (4-1/2” (114 mm) - 6-1/2” (165 mm) WALL THICKNESS) OR #800-WPT2 (6-1/2” (165 mm) - 12-1/2” (318 mm) WALL THICKNESS), MUST BE USED ON ALL HORIZONTAL VENT RUNS. -
Page 28: Series Flex Vent Installation Instructions
IF TERMINATING AGAINST VINYL SIDING, A VINYL SIDING PROTECTOR, INCLUDED WITH THE #844 AND #845 DIRECT VENT KITS, MUST BE USED. FOLLOW INSTRUCTIONS INCLUDED. IMPORTANT: The Kozy Heat wall pass-thru, part #800-WPT or #800-WPT2, must be used on all horizontal vent applications regardless of which vent system you are using. - Page 29 VENTING (Flexible #800 Series cont.) Apply a liberal bead of exterior sealant around the outer edge of termination box (A), placing the assembly through opening in exterior wall. Place screws through the four slots (B), securing it in place. Gently pull 5” & 8” pipes down to the top of extension kit, or top of fireplace if no extension kits were used. 10.
-
Page 30: Termination Vent Cap Location
TERMINATION VENT CAP LOCATION This gas appliance must not be connected to a chimney serving any other appliance. Terminations against vinyl siding must use a vinyl siding protector. Follow instructions included. DO NOT RECESS TERMINATION KIT INTO OUTSIDE BUILDING MATERIALS - i.e.: brick, stone, siding, etc. If necessary, extend framing so that termination kit will be exposed once building materials are installed. -
Page 31: Vent Termination Clearances
VENTING (Vertical Cap Requirements) VENT TERMINATION CLEARANCES Roof Pitch H (Min.) Ft. H (Min.) m Flat to 6/12 0.30 Over 6/12 to 7/12 1.25 0.38 Over 7/12 to 8/12 0.46 Over 8/12 to 9/12 0.61 CAUTION: This appliance must not be connected to or joined with any chimney Over 9/12 to 10/12 0.76... -
Page 32: Log Set Installation
LOG SET INSTALLATION ATTENTION: If converting to LP (propane) gas, do so now before installing log set. Follow instructions included with conversion kit. NOTE: Log numbers are located on the bottom of each log. Refer to following instructions and illustrations for proper placement. CAUTION: Do not place logs directly over burner port holes. -
Page 33: Log Set Installation
LOG SET INSTALLATION STEP 3 Position two base logs #6 and #4 log onto burner as shown above. DO NOT ALLOW LOGS TO COVER THE BURNER PORT HOLES. STEP 4 Position logs #8 & #9 onto base logs and log grate. The #8 log is placed over burner jumper tube. PAGE 32... - Page 34 LOG SET INSTALLATION STEP 5 Install logs #5 - #7 as shown. Use a steel or stiff bristle nylon brush to distribute Rock Wool Embers onto logs and burner. Randomly place „Klinkers‟ in this area. Do not place „Klinkers‟ directly on burner ports. PAGE 33...
-
Page 35: Millivolt Board Removal
MILLIVOLT BOARD REMOVAL CAUTION: If the burner and/or pilot have been burning, use the appropriate protection to avoid burns or damage to personal property before removing any components. Models PRC-36 & PRC-36-RF: Turn gas control knob to the „OFF‟ position. Shut off gas supply at the manual shut-off valve. -
Page 36: Millivolt Board Installation
MILLIVOLT BOARD INSTALLATION WARNING: DO NOT OPERATE THIS FIREPLACE WITHOUT SEALING GASKET (LOCATED UNDER THE MILLIVOLT BOARD) IN PLACE. IF GASKETING IS DAMAGED, IT MUST BE REPLACED. Place millivolt board in firebox, aligning the holes in the millivolt board with INSTALL (8) SCREWS holes in the firebox bottom. -
Page 37: Grill Set
GRILL SET UPPER LOUVER, HOOD & LOWER GRILL INSTALLATION & REMOVAL INSTALLATION Slide flange on upper hood into clips in the top of the upper air passage opening. Upper hood clips A. Align hooks in upper louver to slots located in the fireplace face. -
Page 38: Valve And Pilot Assembly Components
PRC-36 VALVE & PILOT ASSEMBLY COMPONENTS ELECTRODE PILOT HOOD PILOT SHIELD THERMOPILE THERMOCOUPLE HI /LO FLAME ADJUSTMENT KNOB GAS CONTROL KNOB PIEZO IGNITOR VALVE TERMINALS ON/OFF ROCKER SWITCH PAGE 37... -
Page 39: Lighting And Shutdown Instructions
PRC-36 LIGHTING AND SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. DUE TO HIGH SURFACE TEMPERATURES, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. This appliance needs fresh air for safe operation and must be installed so there are provisions for adequate combustion and ventilation air. - Page 40 PRC-36 LIGHTING AND SHUTDOWN (cont.) LIGHTING 5 MINUTES Set thermostat to the lowest setting, if installed. Turn off all electrical power to the appliance. Open lower grill to access the gas valve & controls. A. Push gas control knob in slightly and turn clockwise to “OFF”.
- Page 41 PRC-36 LIGHTING AND SHUTDOWN (cont.) TURN BURNER OFF G. To turn the burner „OFF‟, depress the ON/OFF rocker switch to „OFF‟, flip „off‟ wall switch or adjust setting on the thermostat or remote control. NOTE: The pilot will stay lit. TURN PILOT OFF H.
-
Page 42: Pressure Testing
PRC-36 PRESSURE TESTING IMPORTANT NOTICE: Pressure check taps for the manifold (outgoing) and inlet (incoming) pressure have been incorporated into the valve. The pressure tap marked „OUT‟ measures outgoing pressure and the pressure tap marked „IN‟ measures incoming pressure. Follow instructions below for proper testing procedures. -
Page 43: Prc-36-Rf Valve And Pilot Assembly Components
PRC-36-RF VALVE & PILOT ASSEMBLY COMPONENTS INLET PRESSURE OUTLET GAS CONTROL PRESSURE KNOB PIEZO MOTOR PILOT ADJUSTMENT SCREW MOTOR FUEL CONVERSION COVER PLUG PILOT RF VALVE (bottom view) THERMOPIL ELECTRODE WIRING THERMOPILE TERMINALS ANTENNA WHITE TERMINALS WHITE DOTS PAGE 42... -
Page 44: Prc-36-Rf Lighting And Shutdown Instructions
PRC-36-RF LIGHTING AND SHUTDOWN FOR YOUR SAFETY - READ BEFORE LIGHTING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. DUE TO HIGH SURFACE TEMPERATURES, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY. This appliance needs fresh air for safe operation and must be installed so there are provisions for adequate combustion and ventilation air. - Page 45 PRC-36-RF LIGHTING AND SHUTDOWN (cont.) LIGHTING Turn off all electrical power to the appliance. 5 MINUTES Open lower grill to access the gas valve & controls. A. Push control knob in slightly and turn clockwise to the OFF position. Wait five (5) minutes to clear out any gas.
- Page 46 PRC-36-RF LIGHTING AND SHUTDOWN (cont.) IMPORTANT: INITIAL USE OF TRANSMITTER On the initial use of the transmitter, a recognition operation is required between the receiver / valve and the transmitter. 2 SECONDS Turn gas control knob to the PILOT position. Move LOCAL / REMOTE switch to the LOCAL position for at least two (2) seconds, then move switch to the REMOTE position.
-
Page 47: Prc-36-Rf Pressure Testing
PRESSURE TESTING (PRC-36-RF) IMPORTANT NOTICE: Pressure check taps for the manifold (outgoing) and inlet (incoming) pressure have been incorporated into the valve. The pressure tap marked „OUT‟ measures outgoing pressure and the pressure tap marked „IN‟ measures incoming pressure. Fol- low instructions below for proper testing procedures. -
Page 48: Prc-36-Rf Remote Receiver Functions
PRC-36-RF REMOTE RECEIVER FUNCTIONS IMPORTANT: PLEASE REVIEW AND RETAIN THE INSTRUCTIONS INCLUDED WITH THE RF TRANSMITTER. IT PRO- VIDES ADDITIONAL INFORMATION AND DETAILS CONCERNING THE OPERATIONAL PROCEDURES AND FUNCTIONS FOR THE RF REMOTE CONTROL. FUNCTIONS: Flame powered system. Flame powered flame modulation. Electronics integrated into valve to provide thermostat, flame, and fan functions with RF commands. -
Page 49: Prc-36-Rf Remote Receiver Functions
PRC-36-RF REMOTE RECEIVER FUNCTIONS (cont.) FIRST USE OF TRANSMITTER: STATUS ACTION Begin communication between transmitter and Move LOCAL/REMOTE Switch to LOCAL position for at least two seconds; then move receiver / valve. switch to the REMOTE position. Transmit unique code. Press Fan or Flame key within 30 seconds. -
Page 50: Finalizing The Installation
FINALIZING THE INSTALLATION FLAME APPEARANCE: Flame appearance is affected by several factors including altitude, venting configuration and fuel quality. Although the venturi setting has been factory set, adjustments may be necessary for optimal performance and visual aesthetics. When fireplace is first lit, the flames will be blue. The flames will gradually turn yellowish-orange during the first 15 minutes of opera- tion. -
Page 51: Restrictor Troubleshooting / Installation After Termination Completion
FINALIZING THE INSTALLATION RESTRICTOR USAGE: Turn the fireplace on and allow to burn for 15 minutes. If flames indicate there is excessive draft (flickering, short flames) or insufficient draft (lifting or ghosting flames) a restrictor may be necessary, or the previously installed restrictor may need to be modified or removed. WARNING: TO AVOID PROPERTY DAMAGE OR PERSONAL INJURY, ALLOW FIREPLACE AMPLE TIME TO COOL BEFORE MAKING ANY ADJUSTMENTS AND / OR INSTALLATIONS. -
Page 52: Heat Damper Operation
HEAT DAMPER This fireplace has been designed to operate with the damper fully open or completely closed depending on heat output desired without com- promising flame appearance. The damper is located at the inside top of the firebox and can be viewed through the glass. The damper control is located under the firebox. -
Page 53: Maintenance
MAINTENANCE The appliance is required to be inspected at least once a year by a MILLIVOLT BOARD SYSTEM professional service person. The compartment below the firebox (behind the lower grill) must be cleaned Annual cleaning of the burner system is required. at least once a year, more frequent cleaning may be required due to excessive lint from carpeting, bedding materials, or other fibrous materials. -
Page 54: Troubleshooting
TROUBLESHOOTING (PRC-36 only) CAUTION: THE FOLLOWING MUST BE PERFORMED BY A QUALIFIED TECHNICIAN NO SPARK FROM ELECTRODE TO PILOT WHEN PIEZO BUTTON IS TRIGGERED. A. Check wiring at back of piezo for proper connection. B. Check wiring at electrode for proper connection. C. -
Page 55: Troubleshooting
TROUBLESHOOTING (PRC-36 only) BURNER WILL NOT LIGHT A. Gas control knob not turned to „ON‟. B. „ON‟/„OFF‟ switch not turned on. C. Remote, wall switch or thermostat not turned „ON‟. D. Plugged main burner orifice. E. Remote, wall switch ,thermostat or „ON/ OFF‟ switch wires defective. ♦... -
Page 56: Troubleshooting
TROUBLESHOOTING (PRC-36 only) PILOT AND BURNER EXTINGUISH WHILE IN OPERATION A. No LP (propane) in tank. ♦ Check tank and refill if necessary. B. Glass frame assembly not installed correctly. ♦ Refer to page 15 in this manual for proper glass frame assembly installment instructions. C. -
Page 57: Prc-36-Rf Troubleshooting
RF REMOTE TROUBLESHOOTING (PRC-36-RF only) AUTO PATH If the manual switch is set to Move switch from LOCAL to REMOTE, press the Mode REMOTE. Press any key button to display AUTO on within 30 seconds. the transmitter, Does the REMOTE PATH transmitter display the room and temperature setting? If the manual switch is set to... -
Page 58: Troubleshooting
TROUBLESHOOTING (PRC-36-RF only) CAUTION: THE FOLLOWING MUST BE PERFORMED BY A QUALIFIED TECHNICIAN NO SPARK FROM ELECTRODE TO PILOT WHEN PIEZO BUTTON IS TRIGGERED. A. Check piezo wiring for proper connection. B. Check position of electrode (1/8” (3 mm) between electrode and pilot). Readjust if necessary. C. -
Page 59: Troubleshooting
TROUBLESHOOTING (PRC-36-RF only) BURNER WON‟T STAY LIT A. Thermopile wires loose at valve terminals. ♦ Adjust if necessary. B. Thermopile wires ground out due to pinched wires. ♦ Free pinched wires if necessary. C Refractory panel placement. ♦ Refractory panels must be tight against firebox walls. It may be necessary to secure panels with high-temp sealant, especially around the intake duct PILOT AND BURNER EXTINGUISH WHILE IN OPERATION A. -
Page 60: Replacement Parts List
REPLACEMENT PARTS LIST Replacement parts are available through your local dealer. Contact them for availability and pricing. REFRACTORY PANELS PRC-36 MILLIVOLT BOARD AND PARTS (Sandstone) PRC-770 Millivolt Board - Nat Gas 700-098 Pilot Hood MTK-G900 (3 pc.) Refractory Panel Set PRC-771 Millivolt Board - LP Gas 700-203... -
Page 61: Warranty
PAGE 60... - Page 62 PAGE 61...
