Mr. Heater MH12C Operating Instructions And Owner's Manual

Mr. Heater MH12C Operating Instructions And Owner's Manual

Gas-fired infra-red portable heater

Advertisement

READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
GAS-FIRED INFRA-RED
PORTABLE HEATER
CYLINDER NOT INCLUDED
If the information in this manual is not followed exactly, a fire or explosion
WARNING:
may result causing property damage, personal injury or loss of life.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any
other appliance.
— An LP cylinder not connected for use shall not be stored in the vicinity of this or any other appli-
ance.
— WHAT TO DO IF YOU SMELL GAS
Do not try to light appliance.
Shut off gas to appliance.
— Service must be performed by a qualified service agency.
— DO NOT LEAVE HEATER UNATTENDED OR IN OPERATION WHILE SLEEPING
Adequate combustion and ventilation air must be provided. Refer to page 3.
OPERATING INSTRUCTIONS
AND OWNER'S MANUAL
MR. HEATER INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216-881-5500
MODEL
MH12CS
MODEL
MH12C
06/10 Revision Cmh #73304
Model #
MH12C
MH12CS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MH12C and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mr. Heater MH12C

  • Page 1 — Service must be performed by a qualified service agency. — DO NOT LEAVE HEATER UNATTENDED OR IN OPERATION WHILE SLEEPING Adequate combustion and ventilation air must be provided. Refer to page 3. MR. HEATER INC., 4560 W. 160TH ST., CLEVELAND, OHIO 44135 • 216-881-5500 Model # MH12C...
  • Page 2: Table Of Contents

    SHUTDOWN AND STORAGE INSTRUCTIONS ... 6 REPLACEMENT PARTS LIST ... 7 WARRANTY ... 8 INSTRUCTIONS FOR ORDERING PARTS ... 8 Mr. Heater | Gas-Fired Infra-Red Portable Heater wARNING: NOT FOR HOME OR RECREATIONAL VEHICLE USE wARNING: FIRE, BURN, INHALATION, AND EXPLOSION HAZARD.
  • Page 3: Hookup Information

    HOOK-UP INFORMATION 1.1 Heater models MH12C and MH12CS are packaged completely assembled except for metal stand. Propane cylinders are not included with models MH12C and MH12CS. 1.2 Remove heater from carton. 1.3 Hold heater in one hand and with the other hand hold propane cylinder vertically and carefully turn clockwise into heater valve- regulator until snug.
  • Page 4: Odor Fade Warning

    CONTACT YOUR FUEL GAS SUPPLIER IMMEDIATELY. DO NOT WAIT! 1. GENERAL INFORMATION A. The Mr. Heater MH12C and the MH12CS are high pressure propane appliances and are designed to be connected to a 14.1 or 16.4 ounce disposable propane cylinder. Every unit is tested...
  • Page 5: For Safe Operation

    Return the heater to the dealer or the address given on last page for repair or replacement. FOR STORAGE: The heater Hi-Med-Lo-Off regulating valve Mr. Heater | Gas-Fired Infra-Red Portable Heater should always be turned to “Off” when the heater is not in Cylinder 16.4 oz.
  • Page 6: Cooking Positions

    Turn the heater’s “Hi-Med-Lo-Off” regulator knob to “Med” (counterclockwise.) To light MH12C, place a lit match across the mesh screen where button on Safety Shutoff Valve. After the heater is lit, continue to hold valve button in for 30 seconds, then release the button slowly.
  • Page 7: Replacement Parts List

    Mr. Heater • Gas-Fired Infra-Red Portable Heater • Model #MH12C and #MH12CS NOTE: WHEN LIGHTING BURNER WITH A MATCH OR TAPER, LIGHT AT SCREEN. (NOT AT ORIFICE) REPLACEMENT PARTS LIST FOR HEATER MODELS MH12C AND MH12CS REF.# ITEM# F273116 F273117...
  • Page 8: Warranty

    1-year period, and is returned at customer expense with proof of pur- chase to Mr Heater, Inc. within the warranty period. Mr. Heater Inc. reserves the right to make changes at any time, without notice or obligation, in colors, specifications, accessories, materials and models.

This manual is also suitable for:

Mh12csF242300Mh15c
