DRILLING YOUR DRUM/BARREL/BUCKET
Econo Plus Feeder will mount to the bottom of any drum or bucke
caution: wear eye protection
Turn drum over, measure and mark the center of the bottom.
Center the template on the bottom of the drum and secure
with tape. Drill two 3/16" Funnel holes and three 5/16"
Feeder Leg holes.
Using a Hole Saw, drill a 2-1/4" hole in the center of the
bottom of your drum.
MOUNTING THE FEEDER
Place Funnel inside Drum with
small end of funnel facing down,
and attach with two Short Bolts
using nuts and washers provided.
Turn Drum upside down.
Place Feeder on Drum.
Attach Feeder Legs to Drum as
shown with Long Bolts using
nuts and washers provided.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if
not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to correct the interference by one or more of the following measures:
•
Reorient or relocate the receiving antenna
Instructions for Econo Plus Feeder Kit
THANK YOU for your purchase of the Econo Plus Feeder Kit.
Please read this sheet before operating the unit. If you should have
any questions about this product or any other Moultrie product,
please contact us using the information below. To help us to better
serve you, please complete and mail the enclosed Warranty Card.
Short
Bolts
Feeder Legs
Drum
•
Increase the separation between the equipment and the receiver
Drum
Funnel
Funnel Holes
t
Feeder Leg Holes
Bolts
Feeder
Long
Bolts
Advertisement
Table of Contents
Related Manuals for Moultrie MFHP81565
Summary of Contents for Moultrie MFHP81565
- Page 1 THANK YOU for your purchase of the Econo Plus Feeder Kit. Please read this sheet before operating the unit. If you should have any questions about this product or any other Moultrie product, please contact us using the information below. To help us to better serve you, please complete and mail the enclosed Warranty Card.
- Page 2 Remove bottom and install a 6-Volt Alkaline (ex. Energizer ) or Moultrie rechargeable battery by attaching the Red Alligator Clip to the positive terminal (+) and the Black Alligator Clip to the negative (-) terminal. Place bottom on unit and secure using wing nut.
