Jøtul Scan 65i Installation And Operation Instructions Manual
Jøtul Scan 65i Installation And Operation Instructions Manual

Jøtul Scan 65i Installation And Operation Instructions Manual

Direct vent gas fireplace insert

Advertisement

Quick Links

CAUTION: THESE INSTRUCTIONS ARE TO
REMAIN WITH THE HOMEOWNER.
WARNING: If the information in these
instructions is not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call you gas supplier from a
neighbor's phone. Follow the gas supplier's
instruction.
• If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed
by a qualfied installer, service agency or the
gas supplier.
In the Commonwealth of Massachusetts, a
carbon monoxide (CO) detector shall be
installed in the same room as the appliance.
Installation and

Operation Instructions

ATTENTION : CES INSTRUCTIONS DOIVENT
DEMUERER AVEC LE PROPRIÉTERE D'UNE
MAISON.
AVERTISSEMENT: Assurez-vous de bien
suivreles instructions données dans cette
notice pour réduire auninimum le risque
d'incendie ou d'explosion ou pour éviter tout
dommage matériel, toute blessure ou la mort.
Ne pas entreposer ni utiliser d'essence ni
d'autres vapeurs ou liquides inflammables
dans le voisinage de cet appareil ou de tout
autre appareil.
QUE FAIRE SI VOUS SENTEZ UNE ODEUR
DE GAZ:
• Ne pas tenter d'allumer l'appareil.
• Ne touchez à aucum interrupteur. Ne pas
vous servir des téléphones se trouvant
dans le bâtiment où vous trouvez.
• Appelez immédiatement votre
fournisseur de gaz depuis un voisin. Suivez
les instructions du fournisseur.
• Si vou ne pouvez rejoindre le fournisseur
de gaz, appelez le service des incendies.
L'installatione l'entretien doivent être
assurés par un installateur ou un service
d'entretien qualifié ou par le fournisseur
de gaz.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Scan 65i and is the answer not in the manual?

Questions and answers

Summary of Contents for Jøtul Scan 65i

  • Page 1: Operation Instructions

    Installation and Operation Instructions ATTENTION : CES INSTRUCTIONS DOIVENT CAUTION: THESE INSTRUCTIONS ARE TO DEMUERER AVEC LE PROPRIÉTERE D’UNE REMAIN WITH THE HOMEOWNER. MAISON. WARNING: If the information in these AVERTISSEMENT: Assurez-vous de bien instructions is not followed exactly, a fire or suivreles instructions données dans cette explosion may result causing property notice pour réduire auninimum le risque...
