Summary of Contents for Jensen JSB-200
- Page 1 WALL MOUNTABLE 2.0-CHANNEL BLUETOOTH SOUNDBAR SPEAKER USER MANUAL JSB-200 PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE.
-
Page 2: Dear Jensen® Customer
The serial number of this product is found on its back cover. You should note the serial number of this unit in the space provided as a permanent record of your purchase to aid in identification in the event of theft of loss. Model Number: JSB-200 Serial Number: ____________________... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS When used in the directed manner, this unit has been designed and manufactured to ensure your personal safety. However, improper use can result in potential electrical shock or fire hazards. Please read all safety and operating instructions carefully before installation and use, and keep these instructions handy for future reference. -
Page 4: Important Note
16. Battery shall not be exposed to excessive heat such as sunshine, fire or the like 17. Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type. 18. Do not attempt to dismantle, open or repair this product yourself. If a fault occurs, seek advice from your local qualified service technician or contact the distributor via the telephone number at the back of this instruction manual. -
Page 5: Installations
4 x Anchor (For Wall Mounting) 4 x Flat Head Screws (For Wall Mounting) INSTALLATIONS Placing the JSB-200 on a table Ventilation When placing the Sound Bar on an entertainment center, bookshelf, or any type of enclosed space, be sure to allow at least 2-3 inches of space around the Sound Bar for ventilation. - Page 6 Mounting the JSB-200 on a wooden wall It’s important to be sure there are no electric, gas or water lines located behind the wall where you are attaching the sound bar. We recommend having this speaker professionally installed. Use the included wall mounting accessories and template to attach the sound bar to the wall.
-
Page 7: Main Unit
LOCATION OF CONTROLS MAIN UNIT Front View Back View Right Hand Side View... -
Page 8: Remote Control
MODE INDICATOR LED SUBWOOFER OUT CONNECTOR AUX-IN 1 L/R RCA CONNECTORS DC IN JACK 5. VOLUME + BUTTON POWER ON/STANDBY ; SOURCE BUTTON 7. VOLUME - BUTTON AUX-IN 2 JACK 9. REMOTE INFRARED SENSOR REMOTE CONTROL 1. POWER ON/STANDBY BUTTON 2. -
Page 9: Getting Started
GETTING STARTED CONNECTING THE JSB-200 TO EXTERNAL AUDIO DEVICES You can connect the JSB-200 audio input to the audio output of your television or DVD Player. Please see figure below. NOTE: 1. Make sure that the power is turned off when connecting or disconnecting the other devices. -
Page 10: Bluetooth Operation
1. With the power on, press the SOURCE button on remote control or tap the /SOURCE button on main unit repeatedly to select Bluetooth mode. The Mode Indicator LED turns blue and will be flashing. The JSB-200 is now ready to pair (link) with your Bluetooth device. - Page 11 Bluetooth mode, the Mode Indicator LED turns blue and begins flashing. 3. After the Bluetooth device is paired with the JSB-200, wait for 5 seconds and then press the PLAY/PAUSE button on remote control to start music playback from your cell phone or Bluetooth device.
-
Page 12: Subwoofer Output
2. Select the JSB-200 from the devices list on your cell phone for linking. The Mode Indicator LED stops flashing and remains lit blue if the JSB-200 and your cell phone have been re-linked successfully. -
Page 13: Auxiliary Input
LISTENING TO AUDIO FROM A TV/DVD PLAYER/VCR OR DVR You can connect the JSB-200 to other external audio devices using the AUX-IN 1 RCA connectors located on the back of the unit. 1. Connect the external TV/DVD/VCR/DVR to AUX-IN 1 RCA connectors on the back of the unit (RCA connection cable included). -
Page 14: Care And Maintenance
CARE AND MAINTENANCE 1. Do not subject the unit to excessive force, shock, dust or extreme temperature. 2. Do not tamper the internal components of the unit. 3. Clean your unit with a dry cloth. Solvent or detergent should never be used. 4. -
Page 15: Specification
Unit gets warm after Turn the unit off for a period of time extended play at This is normal. or lower volume. high volume SPECIFICATION Power requirement: Main Unit AC-DC Adaptor DC 16V, 1.8A Remote Control 1 X DC 3V CR2025 lithium Battery At Spectra, environmental and social responsibility is a core value of our business. - Page 16 90 DAY LIMITED WARRANTY AND SERVICE VALID IN THE U.S.A ONLY SPECTRA MERCHANDISING INTERNATIONAL, INC. warrants this unit to be free from defective materials or factory workmanship for a period of 90 days from the date of original customer purchase and provided the product is utilized within the U.S.A.
