- Page 1 CHYN4590A Bluetooth Headset HS801 Support Both Headset Profile and Hands Free Profile User's Guide...
-
Page 2: Table Of Contents
CONTENTS Preface ...1 What is Bluetooth Wireless Technology? How to Use Your Headset? Operating Your Headset ...2 Headset Features ...3 Charging Your Headset ...4 Wearing the Headset ...5 Turning the Headset On or Off Pairing Your Headset and Phone Volume Adjustment ...10 Placing and Receiving Calls Headset Indicator LED... - Page 3 CONTENTS Additional Information ...15 Product Care ...15 Potentially Explosive Atmospheres Power Supply ...16 Emergency Calls ...17 Battery Information ...18 Declaration of Conformity ...16 ...56...
- Page 4 ...20 ...20 ...21 ...21 ...22 ...23 ...24 ...27 ...28 ...29 ...30 ...33...
- Page 5 ...34 ...34 ...35 ...35 ...36 ...36 ...56...
- Page 6 ...38 ...38 ...39 ...40 ...41 ...42 ...43 ...46 ...46 ...48 ...49 ...52...
- Page 7 ...53 ...53 ...54 ...54 ...55 ...55 ...56...
-
Page 8: Preface
Preface Motorola Bluetooth Headset HS801 is a cordless mobile solution built on Bluetooth wireless technology. Please read the instructions before using your headset. Note: HS801 is equivalent to CHYN4590A What is Bluetooth Wireless Technology? Bluetooth wireless technology propels you into a new dimension in connectivity. -
Page 9: Operating Your Headset
Handle incoming and outgoing calls with the headset multifunction control button (MFB). Use voice activation to make calls. Note: The HS801 supports both Headset and Hands Free Bluetooth Profiles for increased functionality Note: and compatibility with more products. Operating Your Headset... -
Page 10: Headset Features
Headset Features Indicator LED Provides visual cue about headset status. Volume down key Adjusts speaker (receive) volume down. Volume up key Adjusts speaker (receive) volume up. Multi-function button (MFB) Controls several headset functions. Microphone Picks up your voice input. Speaker Plays the sound you receive on the call. Earhook Attaches headset to ear. -
Page 11: Charging Your Headset
Operating Your Headset Charging Your Headset First Time Use Before you can use your headset, you need to charge its self-contained Li-ion battery for 24 hours. Recharging When you hear 5 rapid beeps through the headset speaker, repeated at 20-second intervals, the headset battery needs to be charged. You could only use the headset for about 10 minutes after the beeps. -
Page 12: Wearing The Headset
How to Charge Step 1 Plug the Motorola charger into the headset, with the charger's release tab facing up and the headset facing down. 2 After a full charge, remove the charger from the electrical outlet, press the release tab, and detach the charger cord from the headset. - Page 13 Operating Your Headset Step 1 Hook the headset vertically on your right ear. 2 Turn your headset toward back, and point the microphone toward your mouth.
-
Page 14: Right Or Left Ear
Right or Left Ear The direction of the ear clip has to be changed should you decide to wear the headset on your left ear. To Adjust the Ear Clip for Left-ear Use: Operating Your Headset... -
Page 15: Turning The Headset On Or Off
Turning the Headset On or Off To Turn the Headset On Press and hold the headset MFB and side key (Volume down key or Volume up key) together for more than 2 seconds, then the headset will light up. About 3 seconds later, the indicator LED will begin flashing, and you could start the operation. - Page 16 2 Perform a device discovery from the phone. 3 Select the Motorola HS from the discovered devices list and confirm the following on screen prompts. 4 When prompted by the phone, enter the passkey 0000 and the headset will confirm to pair successfully with 5 rapid flashes.
-
Page 17: Volume Adjustment
Operating Your Headset Volume Adjustment Headset listening volume can be adjusted during a call. To Adjust the Listening Volume To turn down the volume, press the headset Volume down key. To turn up the volume, press the headset Volume up key. Volume up key Volume down key... -
Page 18: Placing And Receiving Calls
Placing and Receiving Calls Your headset supports both Hands Free and Headset Profiles. Accessing call functions depends on which profile your phone supports. You can activate call functions for both Hands Free and Headset Profiles according to the following table: Note: 1.Some phones do not support all features listed. - Page 19 Device Status Function Phone Make a voice dial call On-user Dial a dials number number On-voice Redial a dialing number turned on or off On-in call Short press MFB End a call Put active On-in call call on hold Operating Your Headset Headset Hands Free Profile Short press MFB,...
- Page 20 Device Status Function Phone On-phone Receive a rings call On-phone Reject a call rings On-in call Answer 2nd 2nd call incoming call coming in Toggle On-in call between two 2nd call on active calls hold Transfer call from phone On-in call to headset Operating Your Headset Headset...
-
Page 21: Headset Indicator Led
Headset Indicator LED With charger plugged in: Headset Indicator With no charger attached: Headset Indicator ON (steady) 5 rapid flashes Quick flashes every 3 seconds Slow flashes every 8 seconds Operating Your Headset Headset Charging in progress Charging complete Headset Power off Pairing mode Pairing successful... -
Page 22: Additional Information
Additional Information Product Care Use of non-Motorola original accessories may result in performance deterioration, product damage, injury, or electronic shock, and warranty termination. Do not attempt to disassemble your headset, as it does not contain any components serviceable or repairable by consumers. -
Page 23: Potentially Explosive Atmospheres
Potentially Explosive Atmospheres When surrounded by possible explosive atmosphere, turn off the electronic device as it may generate sparks which can cause an explosion or fire. Explosive atmosphere may include gas stations, fuel or chemical storage facilities, and in environment where metal powders, grain, dust are contained in the air. -
Page 24: Emergency Calls
The charger is designed for indoor use only, and must not be used outdoors. Note: For queries about any exceptions when using Bluetooth equipment, due to national requirements or Note: limitations, please visit www.bluetooth.com. Emergency Calls IMPORTANT! Connection cannot be guaranteed at all times under all conditions as the headset used with the electronic device operates using radio signals, landline and cellular networks. -
Page 25: Battery Information
Battery Information New Batteries The battery is not fully charged when it is new. For first time, please charge for 24 hours before using. Low Battery When the battery is low, there will be 5 fast beeps every 20 seconds to alert the user. - Page 26 Additional Information Use only Motorola original accessories. Use of non-original Motorola accessories could be risky and the warranty is void should cause by using -Motorola orig inal accessories. Do not expose your battery in an environment temperature above +55 C (+131 F).
