Infinova V6822-T Series User Manual

Hd megapixel low light ip minidome camera
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
V6822-T Series
HD Megapixel Low Light IP Minidome Camera

User Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the V6822-T Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infinova V6822-T Series

Summary of Contents for Infinova V6822-T Series

  • Page 1: User Manual

    V6822-T Series HD Megapixel Low Light IP Minidome Camera User Manual...
  • Page 2 Infinova. Infinova reserves the right to change this manual and the specifications without prior notice. The most recent product specifications and user documentation for all Infinova products are available on our web site www.infinova.com.
  • Page 3 Read this manual carefully before installation. This manual should be saved for future use. Important Safety Instructions and Warnings: Electronic devices must be kept away from water, fire or high magnetic radiation. Clean with a dry cloth. Provide adequate ventilation. Unplug the power supply when the device is not to be used for an extended period of time.

  • Page 4: Table Of Contents

    CONTENTS Chapter I System Introduction ..............1 1.1 Product Description................. 1 1.2 Product Features ..................1 1.3 System Requirement ................2 1.4 Product Model ..................3 1.5 Specifications ..................3 1.6 Precautions ....................5 Chapter II Installation Instruction............7 Chapter III IE Browser Settings ...............11 3.1 Equipment Connection................11 3.2 Software Installation ................11 Chapter IV Basic Function Operation ............

  • Page 5: Chapter I System Introduction

    1.2 Product Features Infinova’s V6822-T series camera has the following features and functions: 1/3" progressive scan CMOS sensor IR-Cut Removable (ICR) Filter for Day/Night switching Supports WDR function Sensitivity: 0.01 lux...

  • Page 6: System Requirement

    Supports simultaneous multi-user access and parameters configuration via Web Server Compatible with Infinova’s V2216 digital video surveillance software, easy to integrated with other video surveillance software Provides standard SDK, easily incorporated with the digital surveillance...

  • Page 7: Product Model

    HD Megapixel IP minidome camera, Vandal-resistant, 3-axis, Day/night, 1/3 inch CMOS sensor, H.264/M-JPEG, 1.0 Mpx, PoE/12VDC/24VAC, Surface mount, 3.0-9.0mm vari-focal lens 1.5 Specifications Model V6822-T series Image Sensor 1/3" low light progressive scan CMOS Dynamic Range 72.4dB Lens F1.2, f=3.0-9.0mm X (Panning): 0°~340°;...
  • Page 8 Major stream: 1920 1080 1280 1024, 1280 960, 1280 720, 1024 768, 800 600 (for V6822-T02 series (for Optional Resolution 1280 720, 1024 768, 800 600 V6822-T00 series Minor stream: 720 576, 720 480, 640 480, 352 288, 352 240 Maximum Frame Rate 30fps Variable bit rate;...

  • Page 9: Precautions

    1.6 Precautions 1. Do not drop the camera or subject it to strong knock. 2. Do not point the camera lens toward the sun or other strong light. 3. Do not install the camera in environment with temperature beyond the acceptable range (from -10°C to 50°C).
  • Page 10 10.The camera power supply can be 12VDC/24VAC or PoE. Be sure of the +/- terminal correct when the camera is connected with 12VDC power supply. 24VAC power supply must be isolated power. 11.Firstly perform network settings after login. Gateway IP address should be set to the IP address of the gateway that the device connects to.

  • Page 11: Chapter Ii Installation Instruction

    CHAPTER II INSTALLATION INSTRUCTION Step 1: Prepare mounting holes According to the figures below to drill mounting holes and cable hole at the desired position. Figure 2-1 Base (Unit: mm) Figure 2-2 Step 2: Install upper housing Loosen the three mum-head screws in bubble flange and take off the bubble. For ease of installation, upper housing and dome bubble are connected with a safety rope.
  • Page 12 (See Figure 2-4 for location.) Figure 2-4 V6822-T series cameras support bi-directional audio, providing with 1-ch audio input and 1-ch audio output. They also support 2-ch alarm inputs and 1-ch relay output. In addition to 12VDC/24VAC power supply, they can work on power over Ethernet (PoE).
  • Page 13 3-axis adjustment. It allows 0°~340° panning adjustment, 0°~80° tilting adjustment and 0°~340° rotating adjustment. Figure 2-5 Step 4: Install dome bubble Install the bubble flange to upper housing. Align the screw holes of the two parts. Rotate the bubble to make the gap of the shielding cover align with the lens.
  • Page 14 Figure 2-7 Dimensions (Unit: mm) Figure 2-8...

  • Page 15: Chapter Iii Ie Browser Settings

    Must install InfiPlayerAX control and equip with Directx 9.0c. 3.1 Equipment Connection V6822-T series IP minidome camera can be directly connected to a computer, or connected to a network. Note: Check whether the connection is tight or not before power-on.
  • Page 16 successful login. Click the link to run, or store the exe file, then run it. Figure 3-1 If the installation fails, check whether there is video viewed through other IE window or page. You should close the video or the IE window directly. If it successes, click refresh, you can view the live video.
  • Page 17 Figure 3-4 Note: If InfiPlayerAX control installation falls, the live video won’t display. Then, you should change the IE security level. 1. Click “Tool” in the menu bar, and then select “Internet Options” from the drop-down menu. 2. Select “Security” in the pop-up Internet options, as shown in the following figure: 3.

  • Page 18: Chapter Iv Basic Function Operation

    CHAPTER IV BASIC FUNCTION OPERATION This chapter mainly introduces the settings and operation of V6822-T series. 4.1 Live View Start IE browser after the server is powered on for about 50 seconds, and then enter IP address, such as http://192.168.1.100 (default), in the address field.
  • Page 19 Figure 4-2 Live View V6822-T series IP minidome camera supports H.264 and M-JPEG video compression formats. After successful login, it enters H.264 major stream live video interface. Users can also select H.264 minor stream or MJPEG from the dropdown list of stream type. In the H.264 major or minor stream type, users can do recording, snapshootting, and audio in/out settings.
  • Page 20 Users can set the snapshootting and recording storage path in the audio and video settings interface. indicates audio input/output disabled. Click the buttons to enable audio input/output and then the buttons will be shown as indicates that the motion detection and privacy mask functions are disabled.

  • Page 21: System

    With the help of navigation menu on the left, Super user can perform the following operations: Basic Information View, Time Settings and Advanced Settings, Network Settings, Camera Settings (including Basic Set, Effect Set, White Balance, Reset), Audio & Video Settings, Alarm Settings, Account Settings (Add/Delete User, Change Password), Log, etc.
  • Page 22 Time Zone Settings Time Zone: Select the desired time zone in the scroll box, and then click “Save” to save it. There are 33 time zones for your selection. If Daylight Saving Time is applied in your region, please enable the daylight saving time.
  • Page 23 Software Update Free software update is provided for V6822-T series camera, and this update service can reduce system maintenance budget. According to system update requirement submitted by user, we will send update letter for confirming the version of the product and provide the latest software for download, and help user to update the V6822-T series camera.
  • Page 24 Note: Available only for the super user. Factory Settings V6822-T series camera provides online reset function, which greatly facilitates reset adjustment. Select “Keep current IP unchanged”, click “Reset” button and the system will pop up a message as below: Figure 4-8 Click “OK”, all the parameters (excluding IP address) will be reset to the...
  • Page 25 factory default settings. There is time prompt in the web page during reset. After reset, it will skip to new web page. If current IP unchanged, you can access web page directly. If IP address resets to 192.168.1.100, you can’t access web page. Then, you have to set PC’s IP address to 192.168.1 section, such as 192.168.1.25.

  • Page 26: Network Settings

    4.3 Network Settings Click “Network” in the navigation bar, and the following interface will display: Figure 4-9 Network Settings 9 options tabs are available: Network, FTP, SMTP, HTTPS, 802.1X, QOS, IGMP, SIP and MDA. 4.3.1 Network Settings In the Network Settings interface (as shown in the figure above), users can enable or disable DHCP.
  • Page 27 4.3.2 FTP Settings Figure 4-10 FTP Settings V6822-T series camera has the function of alarm associated with FTP upload (alarm triggered image snapshot). Configure server IP, user name and password in the FTP settings and activate FTP handling way in alarm settings, then alarm...
  • Page 28 4.3.3 SMTP Settings Figure 4-11 SMTP Settings User needs to set mail server, recipient, etc in SMTP settings interface. Server IP: Set mail server address. From: Set sender’s mail address. To: Mail address of recipient. CC: Mail address of the person copy to. Authentication: Enable or disable authentication function.
  • Page 29 4.3.4 HTTPS Settings Figure 4-12 HTTPS Settings V6822-T series camera supports HTTPS protocol. You can import the CA certificate in the interface. 4.3.5 802.1X Settings Figure 4-13 802.1X Settings V6822-T series camera supports 802.1X protocol. You have to enable 802.1X authentication when needed.
  • Page 30 (3) Max Throughput (4) Min Delay Recommended: Normal Service. 4.3.7 IGMP Settings Figure 4-15 IGMP Settings V6822-T series camera supports multicast function. In the IGMP interface, users can select the stream type and set the state, multicast IP address and RTP port.
  • Page 31 4.3.8 SIP Settings Figure 4-16 SIP Settings SIP Server: to configure SIP server for device; SIP Server IP: the IP address of SIP server; Port: the port number of SIP server; Server ID: the ID of SIP server; Device ID: the device ID used for registration with SIP server; Alarm ID: the ID registered for device alarm;...

  • Page 32: Camera Settings

    Position Information: the mounting information or instruction for device. Longitude: the longitude of mounting position, as precise to two places of decimal; Latitude: the latitude of mounting position, as precise to two places of decimal. 4.3.9 MDA Settings Figure 4-17 MDA Settings In MDA settings interface, you can set the Sever which the motion detection alarm uploads to.
  • Page 33 Figure 4-18 Basic Settings 4.4.1 Basic Settings You can set the following parameters: Flicker frequency: 50Hz or 60Hz. CVBS: It automatically changes with the flicker frequency. (Notes: analog videos are shut off after MJPEG stream or alarm links are enabled. To enable analog videos, please disable MJPEG stream or alarm link.) Enable or disable backlight compensation or digital WDR.
  • Page 34 4.4.2 Exposure Settings Figure 4-19 Exposure Settings Exposure set, auto aperture, ICR control, ICR switch time, scene, AGC, shutter speed and manual AGC can also be set in this interface. Exposure Set: Manual, Scene and Shutter priority. In the Scene mode, indoor or outdoor can be selected and AGC can be set (maximum 64X);...
  • Page 35 Auto Aperture: to enable or disable auto iris. ICR Control: Auto mode, Night and Day. In Auto mode, the camera can automatically control the day/night switching; in Day mode, videos are in color mode; in Night mode, videos are in black/white mode. AE target: set AE target level.
  • Page 36 Figure 4-21 Effect Set - Mode The camera supports 6 video effect modes. Users can set and save Name, ICR control mode and Scene parameters for each mode. Click “Factoryset” to restore it to default settings.
  • Page 37 The camera provides 7 Scene modes: Normal, Anti Fog, Motion, Entrance, Natrium, Sharpen, USrMode. Each mode matches with a group of parameters, such brightness, sharpness, hue, contrast, saturation and 3D denoise. In the Mode call, users can set effect mode call status and call period. 4.4.4 White Balance Settings Figure 4-22 White Balance Settings The camera has rich white balance modes, including Auto, Manual,...

  • Page 38: Audio & Video Settings

    4.5 Audio & Video Settings Click the button Audio & Video in the navigation bar to display the following interface. Figure 4-23 Video Settings Click the related option tab to enter the setting interface. 4.5.1 Video Settings Users can set the video parameters in the format of H.264 major or minor stream and MJPEG , such as resolution, frame rate and IP rate.
  • Page 39 352 288, 352 240 and closed. the resolution of V6822-T02 series comes to 1920 1080, For MJPEG stream, 1280 1024, 1280 720, 720 480 and closed; the resolution of V6822-T00 series comes to 1280 720, 720 480 and closed. Frame Rate: the number of compressed frames produced by camera per second.
  • Page 40 more details and moving fast, then it takes up more bandwidth to transmit, and reversely it occupies less bandwidth. When the setting goes with constant bit rate, then the image is transmitted under a constant bandwidth. Bit Rate Upper Limit: You have to set the upper limit of bit rate if “vbr” is selected;...
  • Page 41 The camera supports two OSD modes: Mode 1, Mode 2. You can switch the mode only if Text 2 is on. Only if Text 1, Text 2 and Date OSD are set to “On”, you can set the text content and the display position of text and date. Context: Enter the text content in the box of Context, which allows up to 40 characters (lower/upper case letters and X-axis &Y-axis: The title axis location.
  • Page 42 To cancel OSD, set it to “Off” and then click the button “Save”. 4.5.3 Privacy Mask V6822-T series camera supports 4 privacy masks. If there is certain location within the surveillance area where operators are not allowed to see, and thus, Privacy Mask can be applied.
  • Page 43 Figure 4-26 Privacy Mask Settings How to set the privacy masks: Tick the box of motion detection area number. Click the button “Draw” with the mouse, press the left mouse button and drag on the video till a blue frame displays on the screen.
  • Page 44 4.5.4 Motion Detection Figure 4-27 Motion Detection Settings V6822-T series camera supports motion detection. Users can easily set the motion detection areas (up to 4) with the mouse. Note: do turn on motion detection function in Live View interface before motion detection setting (see Section 4.1).
  • Page 45 To cancel a motion detection area, just cancel the box ticking. 4.5.5 Shelter Alarm Figure 4-28 V6822-T series camera supports shelter alarm function. Users can easily set the shelter alarm areas with the mouse. At first, enable shelter alarm. Click the button “Draw” with the mouse, press the left mouse button and drag on the video till a blue frame displays on the screen.
  • Page 46 It will trigger alarm when the video within the area is shielded. Refer to Section 4.6 for alarm contact details. 4.5.6 Link Configure Figure 4-29 For each stream, the total of 90 port and RTSP port is 5. In this interface, you can set the video numbers of 90 port and RTSP port.

  • Page 47: Alarm Settings

    To change the saving path, click the button “Browse” and select the path from the popup dialog box. 4.5.8 Audio Settings Figure 4-31 Audio Settings Sample Rate: 8K. Format: G.711-U. 4.6 Alarm Settings Click “Alarm” in the navigation bar to display the following Alarm Settings interface: Figure 4-32 Alarm Settings...
  • Page 48 “Set” button to take effect. Alarm Schedule V6822-T series camera can set the effective alarm schedule. Select the alarm period (if Sunday is selected, alarm will be enabled during the set period of each Sunday; if everyday is selected, alarm will be enabled during the set period of everyday), and then, set the time period.

  • Page 49: Record Management

    4.7 Record Management V6822-T series IP cameras support storage with SD card. In the Record Management interface, you can set the recording parameters, replay and download the recorded videos. 4.7.1 Record Settings Figure 4-33 Record Settings Recording video type: Select the type of videos to record, major stream or minor stream.
  • Page 50 selected under alarm out contact in the alarm interface, recording is automatically triggered when alarm occurs. You can view the total size, used space and state of SD card and also format it. To remove SD Card when it is being used, please click “Reject”. 4.7.2 Replay Figure 4-34 Replay Video Search: set the start and end time, and then click the search button.
  • Page 51 Figure 4-35 Searching Videos Replay: to replay a video, double click a file in the list with the mouse or select a file and then press the “Play” button . During playing, click to pause or stop playing. Click the button on the right of video window, the right window will disappear, show as below:...
  • Page 52 Figure 4-36 Click the button , the interface will return to the page as Figure 4-35. Download: You can download the videos stored in the SD card to your PC. Select the file from the video list (also you can select multiple files simultaneously using the key “Ctrl”...

  • Page 53: Account Settings

    Save to: Set the path to save the downloaded files. If resetting required, click the button “Browse”. AVI/H.264 drop-down list box: select the downloaded file attribute. In the download list, file total size, status and process will display. Click the button “Start”, and then the files in the list will be downloaded in order. The process shows 100% after downloading is finished.
  • Page 54 Figure 4-39 Add a User (2) Enter the desired User Name and Password (Note: User name and password shall include letter, number and underline only. No special character is allowed. The string length of user name is legal between 1 and 24 characters and that of password is between 5 and 20 characters.) (3) Click “OK”...

  • Page 55: System Log

    Click “OK” button, the selected user would be deleted and the account list would be automatically updated. 3. User Password Change Click button in the account list, the dialog box of Edit User Information will pop up: Figure 4-42 Input the old password, enter the desired new password for twice and then click “OK”...
  • Page 56 Figure 4-44 It can display 30 logs on a page. The user can turn over the pages or skip to the desired page by clicking the below arrows. Click “Delete logs”, a prompt will come out. Then, click “Yes” to clear logs.

  • Page 57: Appendix I Magnetic Ring Filter Instruction

    APPENDIX I MAGNETIC RING FILTER INSTRUCTION To reduce electromagnetic interference that power supply generates, it is necessary to install a magnetic ring filter with the power cable of Infinova front-end IP device. To install a magnetic ring filter with power supply: Step 1: Open the magnetic ring filter and lead the power cable through.

  • Page 58: Appendix Ii Questions & Solutions

    APPENDIX II QUESTIONS & SOLUTIONS The following table describes the symptoms causes and solutions for the problems. Symptoms Possible Causes Solutions Wrong power connection Reconnect power cable Power supply failure Repair or replace power supply PCB fuse damage Replace the fuse Immediate startup after Restart 10 seconds later The network...

  • Page 59: Appendix Iii Cable Diameter Calculation And Lightning & Surge Protection

    APPENDIX III CABLE DIAMETER CALCULATION AND LIGHTNING & SURGE PROTECTION Relation between 24VAC Cable Diameter and Transmission Distance In general, the maximum allowable voltage loss rate is 10% for AC-powered devices. The table below shows the relationship between transmission power and maximum transmission distance under a certain specified cable diameter, on condition that the 24VAC voltage loss rate is below 10%.
  • Page 60 Lightning & Surge Protection The product adopts multi-level anti-lightning and anti-surge technology integrated with gas discharge tube, power resistor and TVS tube. The powerful lightning and surge protection barrier effectively avoids product damage caused by various pulse signals with power below 4kV, including instantaneous lightning, surge and static.
  • Page 61 Infinova 51 Stouts Lane, Monmouth Junction, NJ 08852, U.S.A. Tel: 1-888-685-2002 (USA only) 1-732-355-9100 Fax: 1-732-355-9101 sales@infinova.com V2.2 1311...
