- Page 1 ELLIPTICAL OWNER’S MANUAL Read the ELLIPTICAL GUIDE before using this OWNER’S MANUAL.
-
Page 3: Important Precautions
IMPORTANT PRECAUTIONS SAVE THESE INSTRUCTIONS Read the ELLIPTICAL GUIDE before using this OWNER’S MANUAL. When using an electrical product, basic precautions should always be followed, including the following: Read all instructions before using this elliptical. It is the responsibility of the owner to ensure that all users of this elliptical are adequately informed of all warnings and precautions. - Page 4 DANGER TO REDUCE THE RISK OF ELECTRICAL SHOCK: Always unplug the elliptical from the electrical outlet immediately after using, before cleaning, performing maintenance and putting on or taking off parts. WARNING • To reduce the risk of burns, fire, electrical shock or injury to persons: •...
- Page 5 WARNING TO REDUCE THE RISK OF BURNS, FIRE, ELECTRICAL SHOCK OR INJURY TO PERSONS: • Keep power cord away from heated surfaces. Do not carry this unit by its supply cord or use the cord as a handle. • Do not use other attachments that are not recommended by the manufacturer. Attachments may cause injury. •...
- Page 7 ENTER YOUR SERIAL NUMBER IN THE BOX BELOW: SERIAL NUMBER: AFG SPORT 2.7AE ELLIPTICAL MODEL NAME: » Refer to the SERIAL NUMBER and MODEL NAME when calling for service.
- Page 8 CONSOLE FAN MUSIC PLAYER / READING RACK SPEAKERS CONSOLE UPPER HANDLEBAR PULSE GRIPS WATER BOTTLE HOLDER CONSOLE MAST LOWER HANDLEBAR TOP CAP CRANK MANUAL INCLINE LEVER POWER CORD SOCKET PEDAL ARM STABILIZER TUBE PIVOTING FOOT PADS MAIN FRAME GUIDE RAIL SET LOWER LINK ARM REAR COVER...
-
Page 9: Pre-Assembly
PRE ASSEMBLY TOOLS REQUIRED: F L-Wrench F Flat Wrench UNPACKING F L-Wrench/Screwdriver F Screwdriver (not included) Unpack the product where you will be using it. Place the elliptical carton on a level flat surface. It is recommended that you place a protective covering on your floor. Never open box when it is on its side. - Page 10 ASSEMBLY STEP 1 HARDWARE FOR STEP 1 PART TYPE BUTTON HEAD BOLT SPRING WASHER ARC WASHER Open HARDWARE FOR STEP 1. Attach the STABILIZER TUBE (1) to the MAIN FRAME (2) using 2 BOLTS (A), 2 SPRING WASHERS (B) and 2 ARC WASHERS (C) on each side.
- Page 11 ASSEMBLY STEP 2 HARDWARE FOR STEP 2 PART TYPE BUTTON HEAD BOLT FLAT WASHER SPRING WASHER Open HARDWARE FOR STEP 2. Attach MANUAL INCLINE LIFT LEVER (3) to GUIDE RAIL SET (4) using 4 BOLTS (D), 4 FLAT WASHERS (E), 4 SPRING WASHERS (B) and 4 NUTS (F).
- Page 12 ASSEMBLY STEP 3 HARDWARE FOR STEP 3 PART TYPE SOCKET CAP BOLT SPRING WASHER FLAT WASHER Open HARDWARE FOR STEP 3. Align GUIDE RAIL SET (4) with MAIN FRAME (2) as shown. Lift up on the MANUAL INCLINE LIFT LEVER (3) and place it in one of the holes inside the MAIN FRAME (2).
- Page 13 ASSEMBLY STEP 4 HARDWARE FOR STEP 4 PART TYPE WAVY WASHER FLAT WASHER SPRING WASHER BUTTON HEAD BOLT Open HARDWARE FOR STEP 4. Carefully pull the CONSOLE CABLE (5) NOTE: Be through the CONSOLE MAST (6) using careful not the twist tie located inside the CONSOLE to pinch any MAST (6).
- Page 14 ASSEMBLY STEP 5 HARDWARE FOR STEP 5 PART TYPE FLAT WASHER WAVY WASHER FLAT WASHER SPRING WASHER BUTTON HEAD BOLT Open HARDWARE FOR STEP 5. Slide 1 FLAT WASHER (M), 1 WAVY WASHER (N) and another FLAT WASHER (M) onto the LOWER LINK ARM (10).
- Page 15 ASSEMBLY STEP 6 HARDWARE FOR STEP 6 PART TYPE RUBBER WASHER FLAT WASHER FLAT WASHER SPRING WASHER BUTTON HEAD BOLT Open HARDWARE FOR STEP 6. Slide 1 RUBBER WASHER (O) and 1 FLAT WASHER (M) onto the CONSOLE MAST (6). Slide LOWER HANDLEBAR (12) onto CONSOLE MAST (6) and attach using 1 FLAT WASHER (M) 1 FLAT WASHER (P),...
- Page 16 ASSEMBLY STEP 7 HARDWARE FOR STEP 7 PART TYPE BOLT SPRING WASHER FLAT WASHER Open HARDWARE BAG 7. Slide LOWER LINK ARM (12) into bottom end of LOWER HANDLEBAR (10). Secure the joint with 1 BOLT (Q), 1 SPRING WASHER (B),1 FLAT WASHER (K) and 1 NUT (F).
- Page 17 ASSEMBLY STEP 8 HARDWARE FOR STEP 8 PART TYPE SCREW Open HARDWARE BAG 8. Slide FRONT TOP CAP PIECE (14) and REAR TOP CAP TPIECE (15) over CONSOLE MAST (6) and snap into place. Insert CONSOLE MAST BOOT (16) over TOP CAP (14) and snap into place.
- Page 18 ASSEMBLY STEP 9 NOTE: All hardware for this step is pre-installed. A Remove 4 PRE-INSTALLED BOLTS (18) from the CONSOLE (19). B Attach the CONSOLE CABLES (5) to the CONSOLE (19). C Carefully tuck the CONSOLE CABLES (5) into the CONSOLE MAST (6) before attaching the CONSOLE.
-
Page 19: Elliptical Operation
ELLIPTICAL OPERATION This section explains how to use your elliptical’s console and programming. The BASIC OPERATION section in the ELLIPTICAL GUIDE has instructions for the following: • LOCATION OF THE ELLIPTICAL • POWER/GROUNDING INSTRUCTIONS • FOOT POSITIONING • MOVING THE ELLIPTICAL •... - Page 20 DISPLAY ENTER START STOP...
-
Page 21: Console Operation
CONSOLE OPERATION Note: There is a thin protective sheet of clear plastic on the overlay of the console that should be removed before use. LCD DISPLAY WINDOW: time, distance, calories, watts, RPM, incline, speed, resistance level, heart rate, fan PROGRAMMING KEYS: Used to cycle through programs and user set up C) ENTER / CHANGE DISPLAY: used to confirm selection or change display feedback during workout. -
Page 22: Display Window
*MANUAL INCLINE OPERATION The 2.7AE has an adjustable incline feature to add variety to your workouts. To adjust the incline up or down, stand on the side of the elliptical and place your hand firmly on the top of the shroud. -
Page 23: Getting Started
GETTING STARTED FINISHING YOUR WORKOUT 1) Check to make sure no objects are nearby that will hinder the movement of the elliptical. When your workout is complete, the console will display “workout complete” and beep. Your 2) Plug in the power cord to power the elliptical ON. workout information will stay displayed on the 3) Select User 1, User 2, or Guest using and press ENTER. -
Page 24: Program Information
PROGRAM INFORMATION MANUAL: Adjust your resistance level manually during your workout. STEPS: Promotes healthy activity with 10 step-based workouts calculated counting revolutions as a step. Choose from 1000, 2000, 3000, 4000, 5000, 6000, 7000, 8000, 9000, and 10,000 step workouts. User sets starting resistance and inputs the incline level that the manual incline lever is set to (0, 25, 50, 75, or 100). - Page 25 USING YOUR MEDIA PLAYER 1) Connect the included AUDIO ADAPTOR CABLE to the AUDIO IN JACK on the left of the console and the headphone jack on your media player. 2) Use your media player buttons to adjust song settings. 3) Remove the AUDIO ADAPTOR CABLE when not in use.
-
Page 27: Limited Home-Use Warranty
LIMITED HOME-USE WARRANTY... -
Page 28: Exclusions And Limitations
EXCLUSIONS AND LIMITATIONS WEIGHT CAPACITY = 300 lbs (136.1 kilograms) Who IS covered: FRAME • LIFETIME • The original owner and is not transferable. Manufacturer warrants the frame against defects in workmanship and materials for the lifetime of the original owner, so long as What IS covered: the device remains in the possession of the original owner. - Page 29 SERVICE/RETURNS The Manufacturer does not provide monetary or other • In-home service is available within 150 miles compensation for any such repairs or replacement parts costs, of the nearest authorized Service Provider including but not limited to gym membership fees, work time (Mileage beyond 150 miles from an authorized lost, diagnostic visits, maintenance visits or transportation.
- Page 32 Customer Tech Support. Additional product information is available on our website. TECH SUPPORT USA & CANADA: Advanced Fitness Group 1-855-396-2524 1600 Landmark Drive, support@advancedfitnessgroup.com Cottage Grove WI, 53527 www.afgfitness.com AFG Sport 2.5AE 0615 | © 2015 Advanced Fitness Group Designed & Engineered in the U.S.A. • Made in China...
