WITH MEDIAWAVE COMPUTER
INSTALLATION AND ASSEMBLY
Document Number:
Revision History
Name
A Love
THIS DOCUMENT CONTAINS INFORMATION CONFIDENTIAL AND PROPRIETARY TO MOTION COMPUTING
AND SHALL NOT BE REPRODUCED OR TRANSFERRED TO OTHER DOCUMENTS OR DISCLOSED TO
OTHERS OR USED FOR ANY PURPOSE OTHER THAN THAT FOR WHICH IT WAS OBTAINED WITHOUT THE
MOTION MCW
PROCEDURE
Date
ECN # - General Statement of Change
2009-10-09
ECN-2420 INITIAL RELEASE
PROPRIETARY NOTE
EXPRESSED WRITTEN CONSENT OF MOTION COMPUTING.
002-15-0010
Version
A00
Advertisement
Table of Contents
Summary of Contents for Motion Computing 002-15-0010
- Page 1 A Love 2009-10-09 THIS DOCUMENT CONTAINS INFORMATION CONFIDENTIAL AND PROPRIETARY TO MOTION COMPUTING AND SHALL NOT BE REPRODUCED OR TRANSFERRED TO OTHER DOCUMENTS OR DISCLOSED TO OTHERS OR USED FOR ANY PURPOSE OTHER THAN THAT FOR WHICH IT WAS OBTAINED WITHOUT THE EXPRESSED WRITTEN CONSENT OF MOTION COMPUTING.
-
Page 2: Table Of Contents
OUNT BRACKET ABOUT ONE INCH FROM THE TOP OF THE COLUMN RAIL AND SECURE BY TIGHTENING THE SET SCREWS ASSEMBLE THE BATTERY GAUGE HOUSING ... 13 Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work ... 2 ..3 INCHES OF THE BASE ... - Page 3 MAKE SURE BATTERY CONNECTIONS ARE TIGHT ON BOTH BATTERIES ... 22 REINSTALL THE SHROUD AND COLUMN TOP PLATE ... 23 Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work ..14 OUNTING PLATE REMOVE THE ADHESIVE COVER PAPER FROM THE BACK OF...
-
Page 4: Base With Power Supply Shroud Installed
Remove the plastic Shroud that covers the power supply Tip: Setting the wheel locks will help hold the Base assembly in place. Column assembly Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 5: Lay Base On Its Back
Lay base on its back Position column above base Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 6: Insert Bolts Through The Bottom Of The Cart Into The Column. Thread Each Bolt Before Fully Tightening Any Bolt. Tighten All Four Bolts
Insert bolts through the bottom of the cart into the column. Thread each bolt before fully tightening any bolt. Tighten all four bolts. Set cart upright Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 7: Remove One Screw And Loosen The Other Screw Of The Column Top Plate
Insert decorative cover in the back of the column channel groves. Note: Notice the half moon on the first decorative cover Slide decorative cover down to within 24 inches of the base Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 8: Route Cables Behind The Decorative Cover
Holding cable in the channel and insert second decorative cover in the back column channel groves Note: The half moon cut out is up Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 9: Slide The Decorative Cover Down So It Touches The
Note: The work surface and drawer come pre-assembled. Remove the drawers by pressing the plastic release tabs on the inside of the drawer glide rails. Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 10: Note Where The Allen Set Screws Are Located
Slide the work surface drawer assembly down the rail to about 2 inches (4.4 cm) from the bottom of the rail. Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 11: Tighten The Set Screws
Tighten the set screws Fully tighten the set screws Note: Failure to fully tighten the set screws may result in the assembly dropping Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 12: Reinstall The Drawer By Sliding It Onto The Drawer Rails
Motion MCW with MediaWave Computer – Installation and Assembly Procedure Reinstall the drawer by sliding it onto the drawer rails Document No. 002-15-0010 Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work... -
Page 13: Assemble The Cpu/Monitor Vesa Mount Assembly
Attach metal spacers to the front CPU VESA Mount plate corners Place nylon spacers over the Monitor VESA Mount plate threaded inserts where arrows indicate Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 14: Insert Screws Through The Front Cpu Vesa Mount Plate Hole And Through The Nylon Spacers, Threading Them Into The Monitor Vesa Mount Plate Threaded Inserts
Place the Media Wave Computer onto the front CPU VESA Mount plate, evenly spaced between the metal spacers and connectors facing down Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 15: Attach The Back Cpu Vesa Mount Plate To The Front Cpu Vesa Mount Plate, Using The Threaded Metal Spacers Attached To The Front Plate
Install the Monitor/CPU Mount assembly by sliding the Flush Tilting VESA Mount bracket into the front of the column rail Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 16: Position The Vesa Mount Bracket About One Inch From The Top Of The Column Rail And Secure By Tightening The Set Screws
Assemble the Battery Gauge housing Note position of housing square cutout (offset to left) and cover hole (offset to bottom) Assemble the Mounting plate and Battery Gauge Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 17: Place Them
Place the Mounting plate with the back side facing up, and set the Battery Gauge plate over the fixed mount screws. Attach the Battery Gauge housing to the Mounting plate. Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 18: The B Attery G Auge , And Adhere The B Attery G Auge To The M Ounting P Late Assembly
Turn over the Mounting plate assembly, remove the adhesive cover paper from the back of the Battery Gauge, and adhere the Battery Gauge to the Mounting Plate assembly. Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 19: Plug The Rj45 Battery Gauge Cable Into The Jack, Through The Hole In The Back Of The Battery Gauge Housing
Plug the RJ45 Battery Gauge cable into the jack, through the hole in the back of the Battery Gauge housing. Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 20: Attach The Battery Gauge Mount Plate To The Back Cpu Vesa Mount Plate17
Attach the Battery Gauge Mount plate to the back CPU VESA Mount plate Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 21: 10. Plug In And Secure Monitor Cables
Motion MCW with MediaWave Computer – Installation and Assembly Procedure 10. Plug in and secure monitor cables 11. Plug in and secure computer cables Document No. 002-15-0010 Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work... -
Page 22: Dress The Cables At The Monitor And Cpu Using Corrugated Cable Wrap, Securing With Cable Ties
12. Dress the cables at the Monitor and CPU using corrugated cable wrap, securing with cable ties. 13. Pull the excess cable length to the bottom of the column Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 23: Dress The Cables At The Bottom Of The Column Using Corrugated Cable Wrap, Securing With Cable Ties, And Pulling The Excess Cable Length Into The Sheet Metal Base
14. Dress the cables at the bottom of the column using corrugated cable wrap, securing with cable ties, and pulling the excess cable length into the sheet metal base. Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 24: Install Batteries With Terminal Pointing Out. If The Batteries Are Turned In, The Thermal Sensors Will Read Incorrectly
15. Install Batteries with terminal pointing out. If the batteries are turned in, the thermal sensors will read incorrectly. Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 25: The Unpainted Side Of The Thermal Sensor Must Be In Contact With The Battery Post
16. The unpainted side of the thermal sensor must be in contact with the battery post. 17. Make sure battery connections are tight on both batteries Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work Document No. 002-15-0010... -
Page 26: 18. Reinstall The Shroud And Column Top Plate
Motion MCW with MediaWave Computer – Installation and Assembly Procedure 18. Reinstall the shroud and column top plate Document No. 002-15-0010 Motion Proprietary & Confidential Copyright © 2009 Motion Computing, Inc. as an unpublished work...
