8407 Upright EcoVac ib 4
03/12/2002
1:34 PM
Ecovac vacuum cleaner
Please read and keep these
instructions
getting the best from
your new cleaner...
If your cleaner isn't picking up as
well as it should, please check
• Dustbag
It is important to empty them when full, otherwise the
performance of the cleaner will be impaired. Wash regularly
in warm water and allow to air dry. A spare bag is provided.
• Filters
It is important that the filters are cleaned regularly to allow air
through the appliance
• Blockages
Check the hose for blockages
• Belt
Check and replace damaged or broken belt
Page 1
www.morphyrichards.co.uk
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Morphy Richards Ecovac vacuum cleaner
Summary of Contents for Morphy Richards Ecovac vacuum cleaner
- Page 1 8407 Upright EcoVac ib 4 03/12/2002 Ecovac vacuum cleaner getting the best from your new cleaner... If your cleaner isn’t picking up as well as it should, please check • Dustbag It is important to empty them when full, otherwise the performance of the cleaner will be impaired.
-
Page 2: Important Safety Instructions
• Repairs to electrical appliances are only to be undertaken by trained personnel. Unprofessional repairs can be dangerous for users. • Use only genuine Morphy Richards spare parts and accessories • Never over-extend the hose such that the cleaner is pulled over. If the cleaner is knocked over, switch off before attempting to upright. - Page 3 8407 Upright EcoVac ib 4 03/12/2002 Ì Ê ‰ „ ‚ · Á Accessories included Furniture brush Features ⁄ Upper handle ¤ Flexible hose ‹ Main body › Furniture brush fi Hose connector fl Crevice nozzle ‡ Nested extension tubes (2) ·...
- Page 4 8407 Upright EcoVac ib 4 03/12/2002 Assembly Warning: Do not plug in the cleaner until it is assembled. 1 Carefully unpack all components. 2 Lift cleaner body to upright position. 3 Remove the two screws that are already attached to the body. 4 From the rear of the cleaner, align the handle with groove and slide into the body.
-
Page 5: Using Attachments
8407 Upright EcoVac ib 4 03/12/2002 Using attachments Follow previous steps 1-4 but set the carpet height adjustment knob to the deep carpet setting. 5 Remove the hose connector from the rear of the cleaner and push the required attachment firmly onto the end of the hose. -
Page 6: Changing The Filters
(usually because the brush has been stalled). Replacement belts can be obtained from Morphy Richards or a Service Agent. 1 Disconnect the cleaner from the mains supply. 2 Place the cleaner face down in the flat position. - Page 7 8407 Upright EcoVac ib 4 03/12/2002 9 Remove the belt tunnel blanking plate Ó. 10 Place one end of the new belt over the motor shaft and the other around the pulley end of the brush L. 11 Make sure both brush end plates Ô are fitted.
- Page 8 (or authorised dealer). 4 Where the appliance has been used for hire purposes or non-domestic use. 5 Morphy Richards are not liable to carry out any type of servicing work, under the guarantee. 6 Consumables such as bags, filters and belt are not covered by the guarantee.
