8537 Upright Currys cyclone ib
12/05/2003
Ultralight cyclone vacuum cleaner
Please read and keep these
instructions
getting the best from
your new cleaner...
If your cleaner isn't picking up as
well as it should, please check
• Dust canister
It is important to empty the canister when full, otherwise the
performance of the cleaner will be impaired.
• Filters
It is important that the filters are cleaned regularly to allow air
through the appliance. Wash the cannister filters regularly in
warm water and allow to air dry.
• Blockages
Check the hose, tubes and tools for blockages
• Belt
Check and replace damaged or broken belt
18:12
Page 1
73313
www.morphyrichards.co.uk
Advertisement
Table of Contents
Related Manuals for Morphy Richards 73313
Summary of Contents for Morphy Richards 73313
- Page 1 Wash the cannister filters regularly in warm water and allow to air dry. • Blockages Check the hose, tubes and tools for blockages • Belt Check and replace damaged or broken belt 12/05/2003 18:12 Page 1 Please read and keep these instructions www.morphyrichards.co.uk 73313...
-
Page 2: Important Safety Instructions
• Repairs to electrical appliances are only to be undertaken by trained personnel. Unprofessional repairs can be dangerous for users. • Use only genuine Morphy Richards spare parts and accessories • Never over-extend the hose such that the cleaner is pulled over. If the cleaner is knocked over, switch off before attempting to upright. - Page 3 8537 Upright Currys cyclone ib ⁄ ¤ ‹ › fi fl Accessories included Furniture brush Features ⁄ Vari power slider (only on certain models) ¤ Front cover release ‹ Removable front cover › Hepa exhaust filter fi Carpet height adjustment knob fl...
- Page 4 8537 Upright Currys cyclone ib Assembly Warning: Do not plug in the cleaner until it is assembled. 1 Carefully unpack all components. 2 Lift cleaner body to upright position. 3 Remove the two screws that are already attached to the body. 4 From the rear of the cleaner, align the handle with groove and slide into the body.
-
Page 5: Using Attachments
8537 Upright Currys cyclone ib Using attachments Follow previous steps 1-4 but set the carpet height adjustment knob to the deep carpet setting. 5 Remove the hose connector from the rear of the cleaner and push the required attachment firmly onto the end of the hose. -
Page 6: Changing The Belt
If the power brush stops rotating it is likely that the drive belt has snapped (usually because the brush has been stalled). A spare belt is supplied. Replacement belts can also be obtained from Morphy Richards or a Service Agent. ˆ ı... - Page 7 8537 Upright Currys cyclone ib Removing the floor nozzle cover 1 Disconnect the cleaner from the mains supply. 2 Place the cleaner upside down in the flat position. 3 Use a cross-head screwdriver to remove the two screws at the front and the central screw under the height adjustment mechanism K.
- Page 8 (or authorised dealer). 4 Where the appliance has been used for hire purposes or non-domestic use. 5 Morphy Richards are not liable to carry out any type of servicing work, under the guarantee. 6 Consumables such as the filters and belt are not covered by the guarantee.
