Summary of Contents for Monte Carlo Fan Company 5HS52 Series
- Page 1 ’ WNER ANUAL Ceiling Fan Installation Instructions Total fan weight For 5HS52 Series Fans READ AND SAVE THESE INSTRUCTIONS UALITY EILING FANS...
-
Page 2: Tools Required
Attach the mounting bracket using only the hardware supplied with the outlet box. To reduce the risk of fire or electric shock, do not use this fan with any solid state fan speed control device, or variable speed control. If this unit is to be installed over a tub or shower, it must be marked as appropriate for the application. - Page 3 White White Green Ground Connect black and blue wire from fan to Black or (Hot) wire from house. Connect White wire from Fan to White (Neutral) wire from house. Connect Ground leads from mounting bracket and downrod to Ground lead from house. Refer to Safety Tips section of manual.
- Page 4 Install blades to motor using the 10 motor screws provided. Tighten screws securely. Lift fan to mounting bracket, aligning the “L” shape holes with the scresws on the mount- ing bracket. Turn the fan clockwise to lock in position. Re-install the screws removed in the previous step and tighten securely.
- Page 5 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
