Ceiling Fan Installation Instructions
For 5CSR60AGD Series Fans
READ AND SAVE THESE INSTRUCTIONS
Total fan weigh
with light

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 5CSR60AGD Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Monte Carlo Fan Company 5CSR60AGD Series

  • Page 1 Owner’s Manual Ceiling Fan Installation Instructions For 5CSR60AGD Series Fans READ AND SAVE THESE INSTRUCTIONS Total fan weigh with light...
  • Page 2: Installation

    WARNING – Risk of fire, electric shock, or personal injury, The fan in this box may be either directly supported from a structural framing member of a building and/or may be mounted to an outlet box marked acceptable for fan support of 31.8 kg. (70 lbs.) or less. Most outlet boxes commonly used for the support of luminaires may not be acceptable for fan support and may need to be replaced.
  • Page 3 Thread leadwires and safety cable through downrod. Install yoke cover over downrod onto fan body. Secure mounting neck to the mounting plate with four screws to become a complete mount- ing bracket. Loosen set screw that holds ball.
  • Page 4 . If you have more than one fan with remote. You can set the dip switches to different positiosns to have seperate control. Install arch arms to arch hub using screws removed step 18.
  • Page 5 Make wiring connections as indicated above. White from fan to white from remote marked N. Blue from fan to blue from remote marked light. Black from fan to Black from remote marked L. White from house to white from remote marked AC N .
  • Page 6 Remove finial nut from light fitter. Install finial cap and finial nut and tighten in direction of arrow. WALL MOUNT INSTALL Install wall control unit to outlet box using machine screws provided. Remove hex nut and rubber washer from light fitter. Remove cover by snaping off from top or bot- tom.
  • Page 7: Fan Speed

    The light will cycle from bright to dim to bright until button is released. Light will FORWARD/REVERSE change rotation direction with fan running. MEDIUM SPEED high. To turn fan off press square”. maintain last setting if turned off. Depress rev button allow a few seconds for remote to FAN REVERSE...
  • Page 8: Troubleshooting

    If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
  • Page 9 6/21/06 REV.0 New made from 5GMR manual...
