- Page 1 Owner’s Manual Ceiling Fan Installation Instructions Total fan weight For 5CY60XX Series Fans READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans...
-
Page 2: Installation
Attach the mounting bracket using only the hardware supplied with the outlet box. To reduce the risk of fire or electric shock, do not use this fan with any solid state fan speed control device, or variable speed control. If this unit is to be installed over a tub or shower , it must be marked as appropriate for the application. - Page 3 Wall Control For control of fan and optional light from wall location, follow diagram above. NOTE: A profes- sional electrician is recommended for this type of installation. Secure with cotter pin.
- Page 4 The screws, washers, and motor pads are pre-installed to the blade holders. Attach blade assembly to motor and tighten screws securely. Connect plug from fan to switch house plug. Loosen 2 screws with key slots and remove 1 screw without slot from motor plate and save screw.
-
Page 5: Troubleshooting
If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
