- Page 1 Owner’s Manual Ceiling Fan Installation Instructions Total fan weigh with light For 5CLR66XXD Series Fans READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans...
-
Page 2: Installation
WARNING – Risk of fire, electric shock, or personal injury, The fan in this box may be either directly supported from a structural framing member of a building and/or may be mounted to an outlet box marked acceptable for fan support of 31.8 kg. (70 lbs.) or less. Most outlet boxes commonly used for the support of luminaires may not be acceptable for fan support and may need to be replaced. - Page 3 Thread leadwires and safety cable through downrod. Install yoke cover over downrod onto fan body. Secure mounting neck to the mounting plate with four screws to become a complete mount- ing bracket. Loosen set screw that holds ball.
- Page 4 . If you have more than one fan with remote. You can set the dip switches to different positiosns to have seperate control. Install remote receiver by sliding into opening in the Mounting bracket.
- Page 5 Save screw removed. Plug white wire from fan to white wire from light kit. Then plug black wire from fan to black wire from light kit. Install glass onto light kit, install rubber washer on the top side of the screw nut to hold in place and tight- en in direction of arrow.
-
Page 6: Fan Speed
Remote Control Transmitter MEDIUM SPEED LOW SPEED high. To turn fan off press square”. To turn light on, press light dimmer once quickly. To turn off maintain last setting if turned off. Depress rev button allow a few seconds for remote to... -
Page 7: Troubleshooting
If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet. - Page 8 6/21/06 REV.0 New made from 5GMR manual...
