O
'
WNER
S
M
ANUAL
Ceiling Fan Installation Instructions
Total fan weight
For 4CO28 Series Fans
READ AND SAVE THESE INSTRUCTIONS
Q
C
UALITY
EILING FANS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 4CO28 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Monte Carlo Fan Company 4CO28 Series

  • Page 1 ’ WNER ANUAL Ceiling Fan Installation Instructions Total fan weight For 4CO28 Series Fans READ AND SAVE THESE INSTRUCTIONS UALITY EILING FANS...
  • Page 2: Tools Required

    Attach the mounting bracket using only the hardware supplied with the outlet box. To reduce the risk of fire or electric shock, do not use this fan with any solid state fan speed control device, or variable speed control. If this unit is to be installed over a tub or shower, it must be marked as appropriate for the application.
  • Page 3 White White Green Ground Connect black and blue wire from fan to Black or (Hot) wire from house. Connect White wire from Fan to White (Neutral) wire from house. Connect Ground leads from mounting bracket and downrod to Ground lead from house. Refer to Safety Tips section of manual.
  • Page 4 Lift fan to mounting bracket, aligning the “L” shape holes with the scresws on the mount- ing bracket. Turn the fan clockwise to lock in position. Re-install the screws removed in the previous step and tighten securely. Place blade holders onto blades aligning holes in blade holder with holes in blade.
  • Page 5 If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
