DIRECT VENT GAS FIREPLACE
INSTALLATION AND OPERATING INSTRUCTIONS
WARNING
If the information in these instructions are not
followed exactly, a fire or explosion may result
causing property damage, personal injury or loss of
life.
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
WHAT TO DO IF YOU SMELL GAS
Do not try to light any appliance.
Do not touch any electrical switch.
Do not use any phone in your building.
Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
If you cannot reach your gas supplier, call the fire
department.
Installation and service must be performed by a
qualified installer, service agency or the gas
supplier.
This appliance may be installed in an aftermarket,
permanently located, manufactured (mobile home,
where not prohibited by local codes.
This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not
convertible for use with other gases, unless a certified
kit is used.
For Residential Use-Meets All HUD Requirements For
Manufactured Housing Installations
READ BEFORE INSTALLING OR OPERATING AND SAVE THESE INSTRUCTIONS
3000 SERIES
DUE TO HIGH TEMPERATURES, THE
APPLIANCE SHOULD BE LOCATED OUT OF
TRAFFIC AND AWAY FROM FURNITURE
AND DRAPERIES.
CHILDREN AND ADULTS SHOULD BE
ALERTED TO THE HAZARDS OF HIGH
SURFACE TEMPERATURE AND SHOULD
STAY AWAY TO AVOID BURNS OR
CLOTHING IGNITION.
YOUNG CHILDERN SHOULD BE
SUPERVISED WHEN THEY ARE IN THE
SAME ROOM AS THE APPLIANCE.
CLOTHING OR OTHER FLAMMABLE
MATERIAL SHOULD NOT BE PLACED ON
OR NEAR THE APPLIANCE.
KEEP THE ROOM AREA CLEAR AND FREE
FROM COMBUSTIBLE MATERIALS,
GASOLINE, AND OTHER FLAMMABLE
VAPORS AND LIQUIDS.
Advertisement
Table of Contents
Related Manuals for Monessen Hearth 3000 SERIES
Summary of Contents for Monessen Hearth 3000 SERIES
- Page 1 For Residential Use-Meets All HUD Requirements For Manufactured Housing Installations READ BEFORE INSTALLING OR OPERATING AND SAVE THESE INSTRUCTIONS 3000 SERIES DUE TO HIGH TEMPERATURES, THE APPLIANCE SHOULD BE LOCATED OUT OF TRAFFIC AND AWAY FROM FURNITURE AND DRAPERIES.
-
Page 3: Table Of Contents
IMPORTANT SAFETY INFORMATION: ... 2 PRODUCT SPECIFICATIONS: ... 3 ... 3 LTITUDE NSTALLATIONS LISTING & CODE APPROVAL: ... 3 PRE-INSTALLATION INFORMATION: ... 4 : ... 4 EFORE TART :... 4 IREPLACE OCATION ALL AND EILING LEARANCE : ... 6 OMBUSTIBLE LEARANCES : ... -
Page 4: Important Safety Information
IMPORTANT SAFETY INFORMATION: INSTALLER: Please leave these instructions with the owner. OWNER: Please read and retains these instructions for future reference. IMPORTANT: Read these instructions carefully before installing or trying to operate this appliance. DO NOT use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control, which has been under water. -
Page 5: Product Specifications
PRODUCT SPECIFICATIONS: Models Number Gas Type 320DV4136NV Natural Gas 320DV4136PV Propane/LPG 320DV4742NV Natural Gas 320DV4742PV Propane/LPG 320DV4136NE Natural Gas 320DV4136PE Propane/LPG Electronic Ign 320DV4742NE Natural Gas 320DV4742PE Propane/LPG Electronic Ign High Altitude Installations Gas rate shown above is for altitudes up to 2000 ft. When installing this fireplace at an elevation above 2000 ft, it may be necessary to decrease the input rating by changing the existing burner orifice to a smaller size. -
Page 6: Pre-Installation Information
PRE-INSTALLATION INFORMATION: Before You Start: Read this homeowner manual thoroughly and follow all instructions carefully. Inspect all contents for shipping damage and immediately inform your dealer if any damage is found. Do not install any unit with damaged, incomplete, or substitute parts. Contents: Fireplace –... - Page 7 Figure 2: Fireplace Locations and Minimum Clearances Requirements Figure 1: Fireplace Dimensions...
-
Page 8: Wall And Ceiling Clearance Requirements
2” Min Figure 3: Wall & Ceiling Minimum Clearances Wall and Ceiling Clearance Requirements: Ensure that minimum clearance shown in Figures 3 is maintained. Left and right clearances are determined when facing the front of the appliance. Follow these instructions carefully to ensure safe installation. Failure to follow these requirements may create a fire hazard. -
Page 9: Mantel Clearances
Mantel Clearances: A hood/canopy comes with every appliance. If a combustible mantel is installed, it must meet the clearance requirements detailed in Figure 4. Floor Clearances: The fireplace may be installed on a flat, hard combustible surface (i.e. flat wood, plywood, or particleboard). Be sure that the fireplace rests on a solid continuous floor of platform with appropriate framing support. -
Page 10: Framing Dimensions
Figure 5: Combustible Clearances for Vent Pipe Framing Dimensions: Figure 6: Minimum Framing Dimensions Firebox framing can be built before or after the appliance is set in place. Framing should be positioned to accommodate wall covering and fireplace facing mantel. Figure 6 shows a typical framing of this appliance. Refer to Figure 1 for firebox dimensions. -
Page 11: Finishing Material
Finishing Material: Any remote wiring (i.e. remote control, wall switch, and optional fan) must be done prior to final finishing to Never obstruct or modify the air inlet or outlet grills (louvers) in any manner as it may create a fire hazard. Only noncombustible materials (i.e. -
Page 12: Vent Installation
4. Anchor nailing flanges of the fireplace to the side-framing members using 8d nails or other suitable fasteners. Venting Configuration: These models are approved to use Simpson-Duravent 4 X 6-5/8 Direct Vent Pipe Components and Monessen Hearth System termination kits. No other venting systems or components may be used. See PARTS LIST / ILLUSTRATIONS section for a list of approved vent components. - Page 13 Horizontal Venting with One (1) Elbow: Figure 9: Horizontal Venting with One (1) Elbow Vertical Venting with Two (2) Elbows: Figure 10: Vertical Venting with Two (2) Elbows V, Vertical Elbow (5 inches) 30 inches Max Elbow (5 inches) 30 inches Corner Max 1 foot Min 5 feet Max 2 feet Min...
-
Page 14: Installing Vent Components
Horizontal Venting with Three (3) Elbows: Figure 11: Horizontal Venting with Three (3) Elbows INSTALLING VENT COMPONENTS Before You Start: Plan your installation. Set unit in place and survey how best to vent the unit. Select the appropriate pipe for the installation. - Page 15 Two 45 elbows (P/N 945) may be used in place of one 90 elbow (P/N 990). Any horizontal run must have a 1/4” rise for every one (1) foot of run towards the vent termination. Never allow the vent to run downward. This could cause high temperatures and may present a fire hazard. Always maintain minimum clearances around vent systems.
- Page 16 For Ceiling For ceiling firestops, position a plumb bob over the center of the vertical pipe; to spot a hole through which the pipe will penetrate. Drill a hole through this centerpoint and check the floor for obstructions (i.e. wiring or plumbing). Reposition the fireplace and vent system, if necessary, to accommodate ceiling joists or obstructions.
-
Page 17: Vent Termination
Vent Termination: For Vertical Termination Figure 15: Minimum Vent Height for Various Roof Pitches Major building codes specify a minimum vent height above the rooftop depending on the pitch of the roof. Refer to the above figure for minimum heights, provided the termination cap is at least eight (8) feet from a vertical wall, and two (2) feet below a horizontal overhang. - Page 18 For Horizontal Termination Figure 16: Horizontal Vent Termination Location A=12 inches Clearance above the grade, a veranda, porch, deck, or balcony B=12 inches Clearance to window or door that may be opened. C=12 inches Clearance to permanently closed window. Vertical clearance to ventilated soffit located above the terminal within a horizontal D*=18 inches distance of 2 feet from the centerline of the terminal.
- Page 19 Always maintain minimum clearances around vent systems. The minimum clearances to combustibles for horizontal vent pipe are 3 inches at the top and 1 inch at the sides and bottom of the vent system. For wall firestops, a 1-inch minimum clearance all around the pipe must be maintained. Do not pack the open air spaces with insulation or other materials.
- Page 20 12-1/4” X 12-1/4” Cutout on Vinyl Deflector Shield Figure 18 Horizontal Termination Cap on a Vinyl Siding Wall To locate and install horizontal termination cap (P/N HTC) A wall firestop MUST BE installed if the vent passes through a wall or ceiling. Cut a 10-inch X 10-inch hole through the interior or exterior wall.
-
Page 21: Gas Line And Electrical
GAS LINE AND ELECTRICAL Gas Line Installation: Plumbing connections should only be performed by a qualified, licensed plumber. Main gas supply must be off when plumbing gas line to fireplace or performing service. Consult all codes. All gas piping must be installed to comply with local codes, or in the absence of local codes, with the latest edition of the National Fuel Gas Code ANSI Z223.1. -
Page 22: Electrical Wiring
Figure 19: Gas Pressure Check at Gas Valve Electrical Wiring: Electrical connections should only be performed by a qualified, licensed electrician. Main power must be off when connecting to main electrical power supply or performing service. All wiring shall be in compliance with all local, city, and state codes. - Page 23 Figure 20: Wiring Diagram for Standing Pilot - Millivolt System Figure 21: Schematic Diagram for Millivolt System...
- Page 24 Optional Fan/Blower Systems The junction box for the fan/blower systems has been factory installed. This system requires that 110-120 VAC to be wired to the factory installed junction box before the fireplace is permanently installed. Refer to the figures below for wiring or schematic diagram. Figure 23: Schematic Diagram for Blower Figure 22: Blower Wiring Diagram...
- Page 25 Optional DC Remote Systems These instructions supersede the section entitled “Hearth Mount” in the Millivolt hand held remote instructions supplied with the remote. 1. Cut cable to length (approximately 12”) for placement in the fireplace. 2. Strip back 1/4” of the insulation from both ends of each wire. 3.
- Page 26 Electronic Pilot Ignition Wiring: Do not connect 110-120 VAC to the Remote Wall Switch. The appliance will malfunction or destroyed. Figure 24: Wiring Diagram for Electronic Ignition Figure 25: Schematic Diagram for Electronic Ignition and Blower System WARNING...
- Page 27 Remote Wall Switch Position the wall switch. Refer to Figure 24: Wiring Diagram for Electronic Ignition. Do not extend beyond the 15 feet of wire. Optional Fan/Blower Systems The junction box for the fan/blower systems has been factory installed. This system requires that 110-120 VAC to be wired to the factory installed junction box before the fireplace is permanently installed.
-
Page 28: Final Installation
FINAL INSTALLATION Wall Finishing: Definitions: Combustible Materials - Materials made of or surfaced with wood, compressed paper, plant fibers, or other materials that are capable of being ignited and burned. Such materials are considered combustible even though flameproof, fire retardant, treated, or plastered. Non-Combustible Materials - Materials which will not ignite and burn. -
Page 29: Glass Removal
Glass Removal: Do not operate appliance with the glass front removed, cracked or broken. Replacement of the glass should be done by a licensed or qualified service person. To remove the glass Remove the top bottom louver. Open the lower access door. Using your right hand, simply unlatch the handle by pushing the green handle down. -
Page 30: Rock Wool Placement
Rock Wool Placement: Rock wool needs to be placed on the burner covering the holes at the front of the burner in order to give the “glowing ember” appearance. Refer to the figure above for the placement of rock wool. The rock wool should be pulled apart into chunks roughly the size of a nickel. -
Page 31: Log Placement
Log Placement: This fireplace is supplied with a set of four (4) ceramic fiber logs. Do not handle these logs with your bare hands! Always wear gloves to prevent skin irritation from ceramic fibers. After handling logs, wash your hands gently with soap and water to remove any traces of fibers. -
Page 32: Operating Instructions
OPERATING INSTRUCTIONS Before Lighting the Fireplace: Read the IMPORTANT SAFETY INFORMATION section at the beginning of this homeowner manual. Before lighting, verify the fireplace for possible gas leaks. Before lighting, verify for possible obstructions that could be blocking the vent termination or the front louver. Any component that is found to be faulty must be replaced with an approved component. -
Page 33: Lighting Instructions
STOP! Read the safety information above on this label. Open lower door to reveal RS-OFF-ON rocker switch and gas valve. Turn RS-OFF-ON rocker switch to “OFF”. Turn remote switch to “OFF” Push in gas valve knob and turn clockwise “OFF” Wait five (5) minutes to clear out any gas. -
Page 34: To Turn Off Gas To Appliance
STOP! Read the safety information above on this label. Set the thermostat to lowest setting. Turn off all electric power to the appliance. This appliance is equipped with an ignition device which automatically lights the burner. Do not try to light the burner by hand. -
Page 35: Maintenance
MAINTENANCE Turn off gas before servicing fireplace. It is recommended that a qualified service technician perform these check-ups at the beginning of each heating season. The appliance area be kept clear and free from combustible materials, gasoline and other flammable vapors and liquids. -
Page 36: Vent System
Vent System: The fireplace and venting system should be inspected before initial use and at least annually by a qualified field service person. Inspect the external vent cap on a regular basis to make sure that no debris is interfering with the airflow. -
Page 37: Parts List / Illustration
PARTS LIST / ILLUSTRATION Logs: Item Description 320DV4136 Vent Components: Rear Log 37D0587 Right Log 37D0589 Left Log 37D0588 Top Log 37D0590 Vent Components: Item Simpson Duravent or Monessen P/N 945G 990G 37D0115 (Monessen) HTC (Monessen) HRFK (Monessen) HFTK20 (Monessen) 320DV4742 37D0591 37D0589... - Page 38 Firebox Components: Item Description Standard Features Junction Box Assembly Black Louver Hood/Canopy Temper Glass Frame Assembly Factory Installed Options Standard Firebrick Center Standard Firebrick Right Standard Firebrick Left Ceramic Glass Frame Assembly Brass Louver Blower Motor Thermostat Sensor Accessories/Field Installed Options Blower System Blower with Speed Ctrl Thermostatic Sensor...
- Page 39 Engine Components: Standing Pilot – Millivolt Control Item Description Gas Valve Assembly Pilot Assembly Burner Tube Flexhose with Shutoff Valve Rocker Switch Piezo Igniter Injector Burner Assembly Wire Assembly Accessories Thermostatic Remote Control Remote Control On/Off Wall Switch Kit Wall Thermostat Kit Conversion Kit (Not Shown) 4136 Conversion NG to LPG 4136 Conversion LPG to NG...
-
Page 40: Troubleshooting
TROUBLESHOOTING Standing Pilot Ignition: SYMPTOM POSSIBLE CAUSE Spark ignitor will A. Wire disconnected. not light pilot after repeated triggering of piezo. B. Defective ignitor. C. No gas or low gas pressure. D. No Propane/LPG in tank Pilot will not stay A. - Page 41 The pilot and main A. Inner vent pipe burner extinguish leaking exhaust while in operation gases back into system B. Horizontal vent improperly pitched C. Improper vent cap installation Glass Soots A. Flame impingement on logs Flame burn blue A. Insufficient oxygen and lifts off burner being supplied (ghosting)
-
Page 42: Electronic Pilot Ignition
Electronic Pilot Ignition: SYMPTOM POSSIBLE CAUSE The main burner A. Unit junction box does not light. not electrically grounded or properly connected B. No gas or low gas pressure. C. No Propane/LPG in tank D. Air in gas line Frequent pilot A. - Page 44 Fiber Logs, Catalytic Filter and Aluminized Burners Basic Warranty Monessen Hearth Systems (MHS) warrants the components and materials in your gas appliance to be free from manufacturing and material defects for a period of two years from date of installation. After installation, if any of the components manufactured by MHS in the appliance are found to be defective in materials or workmanship, MHS will, at its option, replace or repair the defective components at no charge to the original owner.
