XOMAX Users Manual XM-VRSU411 Micro FM RADI O Version 1.0 ENGLISH XOMAX X M - V R S U 4 1 1... - Page 2 XOMAX XM-VRSU411 Thank you for purchasing one of our XOMAX products! We appreciate your confi- dence. Enjoy your brand new multimedia unit! Please read the following manual carefully before you install and use the unit. Please save this manual in case you will need to clarify further possible ques- tions regarding installation and usage of our product.
-
Page 3: Table Of Contents
Startup operations Start the playback ......23 Usage of the remote control ....17 10 tracks skip for-/backwards ..23 Replacement of the battery .....17 Select track directly (GOTO) ....23 Unit on/off ........18 XOMAX X M - V R S U 4 1 1... - Page 4 Slide show play / pause ....26 Skip image for-/backwards .....26 Picture viewer manager ....26 Common solutions Disposal / recycling information Disposal of an old unit ....29 Disposal of the battery ....29 XOMAX X M - V R S U 4 1 1...
-
Page 5: Safety Instructions And Precautions
Do not use the unit any further since you detect any kind of technical problems. Leave all the repair opera- XOMAX X M - V R S U 4 1 1... - Page 6 Moisture To avoid the danger of fire or the electric shock do not put the unit in to the moist environment (e.g. adverse weather conditions, inappropriate wet cleaning etc.) XOMAX X M - V R S U 4 1 1...
-
Page 7: Introduction
Specifications Common data Description Operating voltage ......12V DC The XOMAX XM-VRSU411 is a flash XO Backlight color ....Multicolor (7 colors) 1DIN-sized multimedia car radio. Instalation size ..1DIN (shortened depth) A flash XO car radio is a contemporary... -
Page 8: Package Content
4 1DIN installation frame (on unit) 5 faceplate (on unit) 6 ISO port adapter cable The images serve as example. Optically the may vary from the original. XOMAX X M - V R S U 4 1 1... -
Page 9: Operating Elements
(in Radio mode). [MUTE] Mute On/Off. VOL+ boosts the loudness. [CLOCK] Clock settings long press VOL- reduces the loudness. Next track [Play] skip to the next track. XOMAX X M - V R S U 4 1 1... - Page 10 Maximal supported volume: 64 GB. USB USB plug The USB plug is added for reading of USB flash drives in following formats only: FAT32- or exFat- file system. Maximal supported volume: 64 GB. XOMAX X M - V R S U 4 1 1...
-
Page 11: Remote Control
MODE switch between: [Radio], [Audio], [Video], [AUX-IN] and [Bluetooth] APS/BAND Automatic station search/ switch the frequency band [APS] Starts the autosearch and long press storing of the found stations. XOMAX X M - V R S U 4 1 1... -
Page 12: Installation
The detailed installation manual » The connection cables may not be cutted you can find on our homepage www. or short-circuited. Otherwise the warranty xomax.de. becomes invalid. The printed version of a common » Before the installation please make installation manual you can find in sure that your vehicle has the 12 Volt the package. - Page 13 » To avoid a rogue and hazardous short circuit do not lay the yellow cable XOMAX X M - V R S U 4 1 1...
-
Page 14: Connection Schedule - Cinch
Connection schedule – cinch rear left e.g. front left front right (optional) rear right radio-aerial passiv loud speakers e.g. headrest- or ceiling display rear view camera (optional) external display (optional) XOMAX X M - V R S U 4 1 1... -
Page 15: Connection Schedule - Iso Plug / Socket
Connection schedule – ISO plug / socket Connection schedule – ISO plug / socket phantom power radio aerial active permanent current ignition rear right front right front left rear left XOMAX X M - V R S U 4 1 1... -
Page 16: Iso Plug / Socket Pin Assignment
If these problems appear the connec- nments a simple plug'n'play connection tions A4 and A7 should be interchanged. may lead to grievous errors. XOMAX X M - V R S U 4 1 1... -
Page 17: Startup Operations
3. Insert the battery compartment back CR-2025 Lithium battery. into the remote control till it clicks into place. As soon as the remote control does not work proper the battery should be replaced. XOMAX X M - V R S U 4 1 1... -
Page 18: Unit On/Off
Audio radio loudspeakers. - MP3 files (ID3 tag supported) - WMA files The playback control can be achieved via external device only. Images - JPEG XOMAX X M - V R S U 4 1 1... -
Page 19: Basic Functions
EQ preset off first. (prompt " " on the screen) LOUOF Equalizer on/off (prompt " " on the screen) EQOFF Local function on/off (prompt " " on the screen) Stereo/Mono switch XOMAX X M - V R S U 4 1 1... -
Page 20: Preset Equalizer
To turn the key sound off press the 2/SEL button (ca. 2 seconds long) several times till the " prompt appears on the BEPON" screen. Then use buttons to VOL- VOL+ activate/deactivate the function. XOMAX X M - V R S U 4 1 1... -
Page 21: Radio Mode
1, 3, 4, 5, 6 on the front panel type (e.g. music or education). for that). On the screen appears the number of the used memory cell where the station was stored. XOMAX X M - V R S U 4 1 1... -
Page 22: Ta Function (Traffic Announcement)
VOL- VOL+ function on or off. We recommend you to deactivate this function in-city. Otherwise the searching starts each time you drive through the tunnel. XOMAX X M - V R S U 4 1 1... -
Page 23: Playback Mode
10 seconds of each track will it immediately: during the playback be played. press the button either on the front panel or on the remote control. Now you can jog to the required track XOMAX X M - V R S U 4 1 1... -
Page 24: Id3 Tag (Song/Interpreter/Album)
This function is available only during the MP3 files playback; the tags should be stored in these files first. XOMAX X M - V R S U 4 1 1... -
Page 25: Video Playback
Then release the button, the playback resumes. Video file manager Keep the 7/BND button pressed for ca. 2 seconds to call up the Video file manager. XOMAX X M - V R S U 4 1 1... -
Page 26: Picture Viewer
Picture viewer manager Keep the 7/BND button pressed for ca. 2 seconds to call up the picture file manager. XOMAX X M - V R S U 4 1 1... -
Page 27: Common Solutions
Common solutions Common solutions The following advices are generally valid and refer to diverse Xomax models with the similar characteristics. Please note that some articles may refer not to your model exactly and may contain the describtion of features and functions that your model does not support. - Page 28 Though the design of ISO port is standardized, it's pin assigment is not and may vary. Thus in case of mismatch of connections due to different pin assignments a simple plug'n'play connection may lead to grievous errors. XOMAX X M - V R S U 4 1 1...
-
Page 29: Disposal / Recycling Information
To find the nearest collection point or recycling yard please consult your municipal administration. XOMAX distribution worldwide Purchase XOMAX car radio online: https://www.carmediashop.de XOMAX in the world wide web XOMAX manufacturer's information: http://www.xomax.de XOMAX X M - V R S U 4 1 1...
