Technical data sheet for
ROBOT SEMI AUTOMATIC BDR 30 PIECE
Model Number DR2-4/30
•
30 round rolls per operation
•
Conventional tilt head for cleaning
(right to left)
•
Rounding control front mounted
•
Fitted standard with power isolation
switch (side mounted)
•
Quick release shroud for ease
of cleaning
•
Side hook for rounding plates (3 plates
supplied with machine)
Overall Construction
•
Extended base designed to protect machine from
rack damage
•
Heavy-duty steel fabricated body construction for
durability and long life
•
Machine base and body in two-pack paint finish
•
Rounding head covers industrial plastic and easily
removable for cleaning
•
Fitted with nylon wheels as standard
•
Teflon coated rounding head
6244 MOF Robocut FA.indd 3
Operation
•
Manual pressing/degassing
•
Rounding manually activated via front lever
•
Finished roll weights determined by bulk dough
placed on rounding plate
•
Minimum recommended dough capacity per
operation 900 grams
Note: Maximum recommended dough capacity
per operation 3kg
21/4/08 9:48:36 AM
Advertisement
Related Manuals for Moffat Robot Semi Automatic BDR 30 Piece DR2-4/30
Summary of Contents for Moffat Robot Semi Automatic BDR 30 Piece DR2-4/30
- Page 1 Technical data sheet for ROBOT SEMI AUTOMATIC BDR 30 PIECE Model Number DR2-4/30 • 30 round rolls per operation • Conventional tilt head for cleaning (right to left) • Rounding control front mounted • Fitted standard with power isolation switch (side mounted) •...
-
Page 2: Specifications
Technical data sheet for ROBOT SEMI AUTOMATIC BDR 30 PIECE Model Number DR2-4/30 Machine Weight Range / Output • Minimum weight range 30 grams • Maximum weight range 100 grams • Output approx 1800 rolls per hour Specifications • W 620mm x D 620mm x H 1460mm (without handle) •...
