Moffat WALDORF RN8610E Technical Data Sheet

Technical data sheet for
ELECTRIC RANGE STATIC OVEN 900mm
RN8610E, RN8613E, RN8616E, RN8619E
O verall Co ns tru c tio n
• Galvanized steel chassis
• Welded hob with 1.5mm 304 stainless steel bull nose
• Splashback and hob sides 1.2mm 304 stainless steel
• Front panels and oven sides 0.9mm 304 stainless steel
• 150mm legs in 63mm dia. heavy-duty 1.2mm 304 stainless steel
with adjustable feet
Cooktop
• 2.4kW open radiant elements in heavy-duty welded element frames
• Vitreous enamelled element module and hob spill trays
• Hot plate elements with machine finished 8mm steel plate
(optional extra)
• 12mm thick mild steel griddle plates
• 2.5mm 304 stainless steel griddle splash guards
• Aluminised steel internal construction
Griddle sections are standard on RH side. Available on LH side or centre
to order.
Oven
• Fully welded and vitreous enamelled oven liner
• GN 2/1 capacity with 4 position racking
• Heavy-duty easy remove heavy wire chrome rack supports
• Cast iron even heat oven sole plate
• 6.5kW heating elements
• Welded frame drop down door with heavy-duty spring hinge system
• 0.9mm 304 stainless steel door outer
• 1.0mm press formed vitreous enamelled door inner
• High density fibreglass insulated
• Stay cool stainless steel door handle with cast metal handle mounts
• Supplied with two chrome wire oven racks

Heavy-duty construction

2.4kW open radiant elements
Optional hot plate elements
300mm, 600mm and 600mm griddle plate
options
GN 2/1 6.5kW electric static oven
Drop down door
Stainless steel exterior
Easy clean
Easy service
Fully modular
Co n tro ls
• Large easy use control knob - heat resistant reinforced
• Easy view control settings on knob

Cooktop

• Radiant elements with energy regulator controls
• Hot plate elements with energy regulator controls
• 50-320˚C thermostat per 300mm griddle section
• Indicator lights for power and heating for each element control

Oven

• Separate temperature and top heat power regulation controls
• 50-320˚C thermostatic control
• Lo-Hi top heat control
• Indicator lights for power and heating
Cl eaning an d Ser v icing
• All models with easy clean stainless steel external finish
• Removable vitreous enamelled element module and hob spill trays
• Hinge up element and griddle sections
• Removable oven racking and sole plate
• Easy clean vitreous enamel oven and door inner
• Door hinge spring adjustable on unit (door outer removed)
• Door disengages for lift off removal and increased service access
• All parts front accessible from installed position
• Access to all parts from front of unit
