Moffat Blue Seal Evolution G576 Technical Data Sheet

Technical data sheet for
GAS TARGET TOP CONVECTION
OVEN RANGE 900mm
G576
Heavy-duty cast iron top with removable
centre ring
Matched modular height machined top for
seamless work surface
High output dual ring cast iron burner
GN 2/1 gas convection oven
Drop down door
Rear rollers
Stainless steel exterior
Easy clean
Easy service
Fully modular
Overall Construction
• Galvanized steel chassis
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• Hob sides 1.2mm 304 stainless steel
• Splashback 1.2mm 304 stainless steel
• Front panels and oven sides 0.9mm 304 stainless steel
• Vitreous enamelled hob control panel
• 63mm dia. heavy-duty 1.2mm 304 stainless steel adjustable legs at
front and two rollers at rear
Target top
• 3 piece heavy-duty cast iron top with fully machined surface
• Top plates and removable centre with integral spill
protection design
• Cast top reinforced with integral heat fins for heat zone definition
• 45MJ dual ring cast iron burner with single control
• Full pilot and flame failure protection
• 50mm thick refractory brick lined burner box for high heat retention
• 2 stainless steel spill trays
• Supplied with heavy-duty centre casting removal tool
Oven
• Fully welded and vitreous enamelled oven liner
• GN 2/1 capacity with 4 position racking
• Heavy-duty easy remove heavy wire chrome rack supports
• Cast iron even heat oven sole plate
• 30MJ oven burner
• Pilot and flame failure with piezo ignition
• 100W heavy duty motor
• 200mm diameter heavy-duty circulation fan
• Drop down door
• 0.9mm 304 stainless steel door outer
• 1.0mm vitreous enamelled door inner
• High density fibreglass insulated
• Supplied with two chrome wire oven racks
G576
Controls
• Large easy use control knobs - heat resistant reinforced
• Easy view control settings on knobs
Target top
• Variable high to low burner control
• Single control knob for burner and pilot system
• Flame failure pilot burner
• Manual pilot ignition for reliable operation
Oven
• 50-320°C thermostatic control
• Indicator lights for power and heating
• Piezo ignition to pilot burner
• Flame failure
• Fan and burner automatic off when doors open
Cleaning and Servicing
• Removable oven racking and sole plate
• Easy clean vitreous enamel oven and door inner
• Easy clean stainless steel exterior
• Target Top fully serviceable from front of unit
• Bottom sill removable for burner and pilot access
• Access to all parts from front of unit
