Moffat Waldorf GP8910GEC Technical Data Sheet

Technical data sheet for
GAS GRIDDLE CONVECTION ELECTRIC
OVEN RANGE 900mm
GP8910GEC
O verall Co ns tru c tio n
• Galvanized steel chassis
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• Splashback and hob sides 1.2mm 304 stainless steel
• Front panels and oven sides 0.9mm 304 stainless steel
• 150mm legs in 63mm dia. heavy-duty 1.2mm 304 stainless steel with
adjustable feet

Griddle

• 20mm thick machined top plates standard
• Optional ribbed plate sections
• Optional mirror finish hard chrome plates
• 2.5mm thick 304 stainless steel splash guards sides and rear
• 2.0mm thick grease channel
• Two 40MJ 3 bar even heat burners with dual thermostatic controls
• Full pilot and flame failure protection with piezo ignition
• Stainless steel grease drawer
• Overlapping finish at front and rear of plate for easy clean

Oven

• Fully welded and vitreous enamelled oven liner
• GN 2/1 capacity with 4 position racking
• Heavy-duty easy remove heavy wire chrome rack supports
• Cast iron even heat oven sole plate
• 6.5kW heating elements
• 100W heavy-duty motor
• 200mm diameter heavy-duty circulation fan
• Welded frame drop down door with heavy-duty spring hinge system
• 0.9mm 304 stainless steel door outer
• 1.0mm press formed vitreous enamelled door inner
• High density fibreglass insulated
• Stay cool stainless steel door handle with cast metal handle mounts
• Supplied with two chrome wire oven racks
Heavy-duty thermostatic gas griddle
20mm thick griddle plate
Ribbed plate options
Chromed mirror plate options
Top weld sealed plates
80MJ thermostatic griddle burner system
Separate left and right heat zones
GN 2/1 6.6kW electric convection oven
Drop down door
Stainless steel exterior
Easy clean
Easy service
Fully modular
Co n tro ls
• Large easy use control knobs - heat resistant reinforced
• Easy view control settings on knobs
Griddle
• Separate left and right side heat zones
• Two 90-300˚C thermostats
• Flame failure pilot burners
• Piezo ignition to each pilot burner
Oven
• 50-320˚C thermostatic control
• Indicator lights for power and heating
Cl eaning an d Ser v icing
• All models with easy clean stainless steel external finish
• Plate is finished front and rear with overlap construction to remove
cleaning traps
• Control service and gas conversion through front of unit
• Burner service requires plate removal
• Removable oven racking and sole plate
• Easy clean vitreous enamel oven and door inner
• Door hinge spring adjustable on unit (door outer removed)
• Door disengages for lift off removal and increased service access
• Access to all parts from front of unit
