Moffat Turbofan SEL150CX Technical Specifications

TECHNICAL SPECIFICATIONS
Specification Information
Model No.: SEL
Power: 3P + N + E, 400 - 415V, 50 Hz
(48kW heating
Connections: ½" BSP water supply connection and ½" copper drain located at rear of oven
Dimensions: Width: 1650mm
Depth: 1720mm
Height: 2700mm
Weight:

Installation Information

Client to provide the following connections:
Oven requires direct wiring from switchboard. Note: element wattage may vary by 5%
Water connection ½" BSP
Drainage connection ½" copper drain pipe
Note: Oven supply does not include canopies and flues as required by relevant authorities.
Bends or offsets in the flue restrict gas velocity and must be allowed for when designing
the flue height and diameter which will be dependent on the building and local
conditions.
A flue connection is required and is not included in the contract.
Exhaust flue - 200mm in dia (canopy models), 100mm dia (non canopy models)
Clearance: 50mm clearance is required at back and sides of unit
Minimum 2900mm ceiling height
Floor: A concrete or tile surface is preferred.
The floor area is to be flat to within 3mm over whole floor area.
Access: Oven is supplied partially assembled to be fully erected on site.
Largest piece if partially assembled 2130mm H x 1650mm W x 1220mm D
Largest piece if unassembled
In line with policy to continually develop and improve its products, Moffat reserves the right to change specifications and design without notice.
Australia
Moffat Pty Limited
Free Call 1800 023 953
email: vsales@moffat.com.au
www.moffat.com.au
TURBOFAN 150
150
CX
2.5kW motors)
(includes canopy)
(includes canopy)
850kg
50.5kW
2130mm H x 1650mm W x 660mm D
(Electric)
New Zealand
Moffat Limited
Free Call 0800 663 328
email: sales@moffat.co. nz
www.moffat.co. nz
SEL150CX 0403V1
