Moffat Turbofan 150 Technical Specifications

TECHNICAL SPECIFICATIONS
Specification Information
Model No.: SGL150CXN
Power: 3P + N + E, 400 - 415 volt, 50 Hz, 2.42kW
Gas requirements : 200 MJ/hr
Natural gas supply 2.0 kpa to burner gas valve (3/4" BSP connection)
LP gas supply 3.0 kpa to burner gas valve (3/4" BSP connection)
Connections: 1/2" BSP water supply connection and ½" copper drain located at rear of oven
Dimensions: Width: 1820mm
Depth: 1720mm
Height: 2700mm
Weight: 850kg

Installation Information

Client to provide the following connections:
Oven requires direct wiring from switchboard. Note: element wattage may vary by 5%
Water connection ½" BSP .
Note: Oven supply does not include canopies and flues as required by relevant authorities.
Bends or offsets in the flue restrict gas velocity and must be allowed for when designing
the flue height and diameter which will be dependent on the building and local
conditions.
Chimney flue to be taken to atmosphere 127mm diam.
Oven exhaust flue 200mm dia (canopy models), 100mm dia (non canopy models)
Clearance: 50mm clearance is required at back and sides of unit
Minimum 2900mm ceiling height
Floor: A concrete or tile surface is preferred.
The floor area is to be flat to within 3mm over whole floor area.
Access: Oven is supplied partially assembled to be fully erected on site.
Largest piece if partially assembled 2130mm H x 1820mm W x 1220mm D
Largest piece if unassembled
In line with policy to continually develop and improve its products, Moffat reserves the right to change specifications and design without notice.
Australia
Moffat Pty Limited
Free Call 1800 023 953
email: vsales@moffat.com.au
www.moffat.com.au
TURBOFAN 150
(includes canopy)
(includes canopy)
Drainage connection ½"copper drain pipe
2130mm H x 1820mm W x 660mm D
(Gas)
New Zealand
Moffat Limited
Free Call 0800 663 328
email: sales@moffat.co.
www.moffat.co. nz
SGL150CXN 0403V1
