Technical data sheet for
GAS GRIDDLE 1200mm
GP518-B, GP518-CB, GP518-LS, GP518-RB
Heavy-duty thermostatic gas griddle
20mm thick griddle plate
Ribbed plate options
Mirror chromed plate options
Top weld sealed plates
108MJ thermostatic burner system
Separate left, centre, and right heat zones
3 models of base unit
1 model of ventilated refrigeration
base with drawer/door options
Rear rollers
Stainless steel exterior
Easy clean
Easy service
Fully modular

Overall Construction

• 20mm thick machined top plates standard
• Optional ribbed plate sections
• Optional mirror finish hard chrome plates
• 2.5mm thick 304 stainless steel splash guards sides and rear
• 2.0mm thick grease channel
• Three 36MJ 3 bar even heat burners with three thermostatic

controls

• Full pilot and flame failure protection with piezo ignition
• Welded hob surround with 1.5mm 304 stainless steel bull nose
• Side panels 1.2mm 304 stainless steel
• Splashback 1.2mm 304 stainless steel
• Vitreous enamelled control panel
• Stainless steel grease drawer
• Overlapping finish at front and rear of plate for easy clean
Bench mount (supplied as –B model)
• Four 63mm dia. heavy-duty 1.2mm 304 stainless steel bench legs
with adjustable feet.
• Adjustable height 80mm – 105mm
Cabinet base (supplied as –CB model)
• Fully modular for match suite finish
• Double skin 0.9mm 304 stainless steel interior and exterior
• Optional GN 1/1 4 position racking kit (1 or 2 cabinet bays)
• Up to eight 65mm GN 1/1 capacity
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with two
adjustable feet at front and two rollers at rear
Leg stand (supplied as –LS model)
• Fully modular for matched suite finish
• Framed top for connection to Griddle
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with two
adjustable feet at front and two rollers at rear
• Fully modular framed stand shelf with 0.9mm 304 stainless
steel finish
• Suitable for rear or through shelf gas connection to Griddle
• Quick assembly design
GP518-LS
Refrigerated Base (supplied as –RB model)
• Self contained suite matched modular base
• Ventilated system with R134a refrigerant
• -2° to + 8°C temperature (Tropical Climate rated)
• Two GN 1/1 drawers
• 100mm deep pan capacity
• Heavy-duty European telescopic drawer guides
• Magnetic drawer gaskets (replaceable without tools)
• 50mm fully foamed CFC free insulation
• 304 stainless steel exterior and interior
• Anti-corrosion treated evaporator
• No condensate drain required
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with
adjustable feet
• Condensing unit removable through front of unit for service
• Easy clean interior
Controls

Griddle

• Separate left, centre, and right side heat zones
• Three 90-300°C thermostats
• Large easy use control knobs - heat resistant reinforced
• Easy view control settings on knobs
• Flame failure pilot burners
• Piezo ignition to each pilot burner
• Over-temperature safety cut-outs

Refrigerated Base

• Digital control electronic thermostat
• Automatic defrost
• Automatic evaporation of defrost water
• -2° to +8°C temperature range

Cleaning and Servicing

• All models with easy clean stainless steel external finish
• Plate is finished front and rear with overlap construction to remove
cleaning traps
• Control service and gas conversion through front of unit
• Burner service requires plate removal
• Refrigerated Base condenser removable through front of unit
