Technical data sheet for
GAS CHARGRILL 300mm, 600mm, 900mm, 1200mm
G592-B, G594-LS, G596-LS, G598-LS
Heavy-duty construction
Reversible heavy-duty top grates
Interchangeable drop on griddle plates
33MJ/hr stainless steel burners per
300mm section
Rear rollers
Stainless steel exterior
Easy clean
Easy service
Fully modular
Overall Construction
Chargrill
• 2.5mm thick 304 stainless steel side splash guards
• Welded 1.5mm 304 stainless steel bull nose
• Side panels 1.2mm 304 stainless steel
• Splashback 1.2mm 304 stainless steel
• Vitreous enamelled control panel
• Front grease channel
• Welded 1.2mm 304 stainless steel grease trays
• 1.5mm aluminised steel burner box
• Insulated sides
Leg stand
• Fully modular for matched suite finish
• Framed top for connection to Chargrill
• 63mm dia. heavy-duty 1.2mm 304 stainless steel legs with two
adjustable feet at front and two rollers at rear
• Fully modular framed stand shelf with 0.9mm 304 stainless
steel finish
• Quick assembly design
Grates and radiants and baffles
• 150mm wide x 550mm top grate sections
• Top grates reversible for level or inclined use
• Inclined position incorporates flare reducing grate fin design with
grooves to run grease into front collection channel
• Heavy weight castings for high demand performance
• Heavy-duty high efficiency cast iron burner radiants
improve heat retention and protect burners
• Baffles over grease trays to reduce grease collection flare ups
G594-LS
Griddle plates
• Optional extra 300mm wide and 450mm wide x 550mm deep drop on
cast iron griddle sections
• Machined smooth surface finish
• Interchangeable in any position with 2 or 3 sections of top grate
• Multiple griddle sections can be mixed in any positions
• Full 304 stainless steel burners
• 1 x 33MJ/hr burner per 300mm section
• Removable for cleaning
• Full pilot and flame failure protection per burner
Controls
• Individual Hi-Lo gas control to each burner with flame failure
and pilot
• Large easy use control knob - heat resistant reinforced
• Easy view control settings on knob
• Piezo ignition to pilot burner
Cleaning and Servicing
• Easy clean stainless steel external finish
• Lift out radiants, burners and grease tray baffles
• All burner box interior parts lift out for full cleaning access
• Deep stainless steel grease collection drawers
• Access to all parts from front of unit
