Moffat Waldorf FN8224EE Technical Data Sheet

Technical data sheet for
FAST FRI TWIN PAN
ELECTRIC FRYER 450mm
FN8224EE
17kW high performance twin pan fryer
2 digital display temperature control 4 basket
timers
Easy clean stainless steel open pan with 10
year limited warranty
12L per pan oil capacity
25mm (1") drain valves
Stainless steel exterior
Easy service
Fully modular
O verall Co ns tru c tio n
• Stainless steel pan
• Bull nose welded 1.5mm 304 stainless steel
• Splashback 1.5mm 304 stainless steel
• Side panels 1.2mm 304 stainless steel
• Double skin door with 0.9mm 304 stainless exterior
• Hinge out counterbalanced heating elements
• 25mm (1") drain valves
• 150mm legs in 63mm dia. heavy-duty 1.2mm 304 stainless steel with
adjustable feet
• 2 baskets and stainless steel lid supplied standard
Co n tro ls
• Digital display electronic thermostats
• Thermostat range 88-195˚C
• 2 programmable basket timers with countdown display and alarms
per pan
• Heating and basket drop displays
• Programmable melt cycles
• Fail-safe over-temperature safety cut-outs
• Element tilt switch for heating cut-out on element lift
Cl eaning an d Ser v icing
• Open stainless steel pans with hinge out elements for easy clean
• Easy clean basket support bar
• 25mm (1") drain valves for effective draining
• Easy clean stainless steel exterior
• Access to all parts from front of unit
