Moffat Waldorf FN8130G Technical Data Sheet

Technical data sheet for
FAST FRI SINGLE PAN GAS FRYER 600mm
FN8130G
High performance single pan fish fryer
Patented infra-red burner system
Easy clean stainless steel open pan with
10 year limited warranty
31L oil capacity
2 large or 3 standard basket capacity
Large capacity cool zone
32mm (1 / ") drain valve
1
4
Stainless steel exterior
Easy service
Fully modular
O verall Co ns tru c tio n
• Stainless steel pan with 10 year limited warranty
• Bull nose welded 1.5mm 304 stainless steel
• Splashback 1.5mm 304 stainless steel
• Side panels 1.2mm 304 stainless steel
• Double skin door with 0.9mm 304 stainless exterior
• 32mm (1 / ") drain valve
1
4
• 150mm legs in 63mm dia. heavy-duty 1.2mm 304 stainless steel with
adjustable feet
• 3 standard baskets and stainless steel lid supplied standard
Co n tro ls
• Direct action thermostat reacts to + or – 1.0˚C
• Thermostat range 145 – 195˚C
• Over-temperature safety cut-out
• Millivolt gas valve system (no electrical supply)
• Flame failure protection on each pilot
• Piezo ignition to standing pilot burners
Cl eaning an d Ser v icing
• Open stainless steel pans for easy clean
• Easy clean basket support bar
• 32mm (1 / ") drain valve for effective draining
1
4
• Easy clean stainless steel exterior
• Access to all parts from front of unit
