Moffat Waldorf FN8127E Technical Data Sheet

Technical data sheet for
FAST FRI SINGLE PAN
ELECTRIC FRYER 450mm
FN8127E
17kW high performance single pan fryer
Easy clean stainless steel open pan with 10
year limited warranty
27L oil capacity
32mm (1 / ") drain valve
1
4
Stainless steel exterior
Easy service
Fully modular
O verall Co ns tru c tio n
• Stainless steel pan
• Bull nose welded 1.5mm 304 stainless steel
• Splashback 1.5mm 304 stainless steel
• Side panels 1.2mm 304 stainless steel
• Double skin door with 0.9mm 304 stainless exterior
• Hinge out counterbalanced heating elements
• 32mm (1 / ") drain valve
1
4
• 150mm legs in 63mm dia. heavy-duty 1.2mm 304 stainless steel with
adjustable feet
• 2 baskets and stainless steel lid supplied standard
Co n tro ls
• Mechanical thermostat
• Thermostat range 90-200˚C
• Large easy use control with easy view scale
• Fail-safe over-temperature safety cut-out
• Element tilt switch for heating cut-out on element lift
• Indicator lights for power and heating
Cl eaning an d Ser v icing
• Open stainless steel pan with hinge out elements for easy clean
• Easy clean basket support bar
• 32mm (1 / ") drain valve for effective draining
1
4
• Easy clean stainless steel exterior
• Access to all controls from front of unit
