Moffat Blue Seal Evolution GT45E Technical Data Sheet

Technical data sheet for
VEE RAY SINGLE PAN GAS FRYER 450mm
GT45E
High performance single pan fryer
Patented infra-red burner system
Digital display temperature control with 3
product timers
Easy clean stainless steel open pan with 10 year

limited warranty

20L oil capacity
Large capacity cool zone
32mm (1 1 / ") drain valve
4
Rear rollers
Stainless steel exterior
Easy service
Fully modular
GT45E

Overall Construction

• Stainless steel pan with 10 year limited warranty
• Bull nose welded 1.5mm 304 stainless steel
• Splashback 1.2mm 304 stainless steel
• Side panels 1.2mm 304 stainless steel
• Double skin door with 0.9mm 304 stainless exterior
• 32mm (1 1 / ") drain valve
4
• 63mm dia. heavy-duty 1.2mm 304 stainless steel adjustable legs at
front and two rollers at rear
• 2 baskets and stainless steel lid supplied standard

Controls

• Digital display electronic thermostat
• Thermostat range 88-193°C
• 3 programmable product timers with countdown display and alarms
• Straight or temperature compensating cook time control
• Heating and basket drop displays
• Programmable melt cycles
• Over-temperature safety cut-out
• Flame failure protection on each pilot
• Piezo ignition to standing pilot burners

Cleaning and Servicing

• Open stainless steel pan for easy clean
• Easy clean basket support bar
1
• 32mm (1 / ") drain valve for effective draining
4
• Easy clean stainless steel exterior
• Access to all parts from front of unit
