Moffat Blue Seal E44 Technical Data Sheet

Technical data sheet for
TWIN PAN ELECTRIC FRYER 450mm
E44
17kW high performance twin pan fryer
Easy clean stainless steel open pan with 10 year

limited warranty

12L per pan oil capacity
25mm (1") drain valves
Rear rollers
Stainless steel exterior
Easy service
Fully modular
E44
Overall Construction
• Stainless steel pan with 10 year limited warranty
• Bull nose welded 1.5mm 304 stainless steel
• Splashback 1.2mm 304 stainless steel
• Side panels 1.2mm 304 stainless steel
• Double skin door with 0.9mm 304 stainless exterior
• Vitreous enamelled control panel
• Hinge out counterbalanced heating elements
• 25mm (1") drain valves
• 63mm dia. heavy-duty 1.2mm 304 stainless steel adjustable legs at
front and two rollers at rear
• 2 baskets and stainless steel lid supplied standard
Controls
• Mechanical thermostats
• Thermostat range 60-200°C
• Large easy use controls with easy view scale
• Fail-safe over-temperature safety cut-outs
• Element tilt switch for heating cut-out on element lift
• Indicator lights for power and heating (per pan)
Cleaning and Servicing
• Open stainless steel pans for easy clean
• Easy clean basket support bar
• 25mm (1") drain valves for effective draining
• Easy clean stainless steel exterior
• Access to all parts from front of unit
