Moffat Turbofan E27MS Specifications

Full size electric convection oven

Hide thumbs Also See for Turbofan E27MS:

Download this manual See also: Service Manual

4937 E25&E27MS Specs.v3 25/1/06 11:25 AM Page 1

Full Size Electric Convection Oven

Commercial construction

3 full pan capacity

2 wire racks supplied

Bi-direction reversing fan system

15 amp plug-in (NEMA 6 -15P)

60 minute bake timer

Stainless steel outer

Stainless steel door with

full viewing window

Heavy duty stainless steel

door handle

Insulated porcelain inner

Internal lighting

E27MS

Unit shall be a Moffat electrically heated Turbofan convection oven E.T.L. listed (UL Std 197) and NSF-4 listed. The oven shall have

a one piece vitreous porcelain enamel oven liner, stainless steel top and sides with single stainless steel door and full viewing window.

Oven liner shall be insulated on all sides and have capacity for three full size sheet pans. The oven shall have a bi- direction single

reversing fan system for oven bake circulation.The oven shall be controlled by a mechanical thermostat with a range from 120°F to

480°F, a 60 minute bake timer, and oven light switch. Oven shall be able to be bench mounted on 4" legs. Oven shall be fitted with

a NEMA 6 -15P cordset.

E27MS

Order Toll Free 1800 551 8795

E27MS

Need help?

Do you have a question about the Turbofan E27MS and is the answer not in the manual?

Page 1 E27MS Unit shall be a Moffat electrically heated Turbofan convection oven E.T.L. listed (UL Std 197) and NSF-4 listed. The oven shall have a one piece vitreous porcelain enamel oven liner, stainless steel top and sides with single stainless steel door and full viewing window.
Page 2 (76mm) (120mm) In line with policy to continually develop and improve its products, Moffat Limited reserves the right to change specifications and design without notice. Printed in New Zealand S P E C I F I C AT I O N S Electrical requirements 208V, 50/60Hz, 1P+N+E, 3.0kW, 14.4A...
