Moen Waterhill S112 Specifications

FAUCET DESCRIPTION

• Metal spray face and shell with various finishes identified by suffix
• Brass swivel ball assembly

OPERATION

• Self pressurizing design provides strong performance regardless of
line pressure
• Single spray function

FLOW

• Showerhead designed to deliver 2.5 gpm (9.5 L/min) at 80 psi
• EP suffix models are limited to 2.0 gpm (7.76 L/min) at 80 psi

STANDARDS

• Third party certified to meet ASME A112.18.1/ CSA B125.1 and all
applicable requirements referenced therein
• EP suffix models are IAPMO Green listed and third party certified
to WaterSense®

WARRANTY

• Lifetime limited warranty against leaks, drips and finish defects
to the original consumer purchaser
• 5 year warranty if used in commercial installations
Rev. 2/11
10"
(254mm)

CRITICAL DIMENSIONS

(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
S p e c i f i c a t i o n s
WATERHILL™
10" Rainfall Showerhead
Models: S112 series
Models: S112EP series
2 7 /8" (73mm)
www.moen.com
