Moen Vivid TS888 series Specifications

FAUCET DESCRIPTION

• Glass and metal construction with chrome finish
• 1/2" IPS connections
• Includes metal pop-up plug waste assembly
• For use with S948 valve

OPERATION

• Knob style handles
• Maximum handle rotation angle is 90º to full on for either angle
• Hot side counterclockwise to open (clockwise to close)
• Cold side clockwise to open (counterclockwise to close)

FLOW

• Flow is limited to 1.5 gpm max (5.7 L/min) at 60 psi, for products made
before October 2008 flow is limited to 2.2 gpm max. (8.3 L/min)

CARTRIDGE

• 1224 cartridge design
• Nonmetallic and stainless steel material

STANDARDS

• Third party certified to WaterSense®, CSA B125.1, ASME A112.18.1, ICC A117.1
and all applicable requirements referenced therein
• Certified to ANSI/NSF 61/9
• Complies with California Proposition 65 and with the Federal Safe Water
Drinking Act
• ADA for lever handles

WARRANTY

• Lifetime limited warranty against leaks, drips and finish defects to the original
consumer purchaser
• 5 year limited warranty if used in commercial installations
2"
(51mm)
Quick
Connect Hose
Assembly
Rev. 11/08
6-3/8"
(162mm)
8"
(204mm)

CRITICAL DIMENSIONS

1-1/4"
(108mm)
2"
(51mm)
Max Deck
Thickness
1-1/4"
(32mm)
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN

Specifications

VIVID
Two Handle Widespread
Lavatory Faucet Trim
Model: TS888 series
NOTE: THIS FAUCET IS DESIGNED TO BE
INSTALLED THRU 3 HOLES, 1" MIN. DIA.
6-1/4"
(159mm)
3-31/32
(101mm)
4-1/4"
(108mm)
2-1/4"
(51mm)
www.moen.com
