Moen VESTIGE T932 Series Specifications

Two-handle roman tub faucet trim
Hide thumbs


Advertisement

DESCRIPTION
Metal construction with various finishes identified by suffix
OPERATION
Lever style handles with hot and cold indicators
Rotate hot side handle counterclockwise to open
(clockwise to close) and the cold side handle clockwise to
open and (counterclockwise to close)
STANDARDS
Third party certified to CSA B-125, ASME A112.18.1M,
and all applicable requirements referenced therein
• ADA
for lever handles
WARRANTY
Lifetime limited warranty against leaks, drips and
finish defects to the original consumer purchaser
5 year warranty if used in commercial installations
Spout Base
2-3/4" (70mm)
DIA.
Rev. 6/08
9" (229mm)
CRITICAL DIMENSIONS
(DO NOT SCALE)
S p e c i f i c a t i o n s
Two-Handle Roman Tub Faucet Trim
Models: T932 series
Valves: 4992, 4993, 4996, 4997, 4999,
64997, 64999
2-7/8"
(72mm)
Handle Base
2"
(50mm) DIA
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
VESTIGE™
5" (127mm)
MINIMUM
8-1/4"
(209mm)
3-1/2"
(88mm)
www.moen.com
