DESCRIPTION
• Metal construction with various finishes identified by suffix
OPERATION
• Lever style handle operation
STANDARDS
• Third party certified to meet ASME A112.18.1/CSA B-125.1
and all applicable requirements referenced therein
WARRANTY
• Lifetime limited warranty against leaks, drips and
finish defects to the original consumer purchaser
• 5 year warranty if used in commercial installations
2-11/16"
(68mm)
Rev. 5/10
2-1/8"
(54mm)
Wall Opening
2-3/4"
(70mm)
CRITICAL DIMENSIONS
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
S p e c i f i c a t i o n s
MOEN®
Single Function Flow Valve Trim
Models: TL3600 series
www.moen.com
