Moen Show House S932 Specifications

DESCRIPTION

• Metal construction with various finishes identified by suffix
• Includes 10" rainfall showerhead, arm, flange and diverter tub spout

OPERATION

• Lever style handle with temperature indicator on the escutcheon
• Handle operates with counterclockwise rotation through a 270° arc with
off at 6 o'clock and maximum hot at the 9 o'clock position.
Shut off in clockwise direction.
• Adjustable temperature limit stop to control maximum hot water
temperature
• Pressure balancing mechanism maintains selected discharge
temperature to ± 3.6°F (± 2°C)

FLOW

• Showerhead is limited to 2.5 gpm max. (9.5 L/min)

CARTRIDGE

• 1225 cartridge design
• Nonmetallic/nonferrous and stainless steel materials
• Accommodates back to back installations

STANDARDS

• Third party certified to CSA B125.1, ASME A112.18.1, ANSI A117.1,
ASSE 1016, and all applicable requirements referenced therein
• ADA for lever handle

WARRANTY

• Lifetime limited warranty against leaks, drips and finish
defects to the original consumer purchaser
• 5 year warranty if used in commercial installations
Rev. 3/11
(457mm)
10"
(254mm)
8"
(203mm)
2-1/4"
(57mm)

CRITICAL DIMENSIONS

CRITICAL DIMENSIONS
(DO NOT SCALE) (DO NOT SCALE)
S p e c i f i c a t i o n s S p e c i f i c a t i o n s
WATERHILL™ POSI-TEMP®
Single-Handle Tub/Shower (Trim Only)
Models: TS310 series-valve trim only
TS312 series-shower trim only
TS314 series-tub/shower trim
Valves: 2500 series
62300 series
Finished
Wall Line
18"
6-1/8"
(156mm)
4-1/2"
(114mm)
WALL OPENING
Floor Line
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN
C L
www.moen.com
