ShowHouse DIVINE TS253 series Specifications

DESCRIPTION
- Metal construction with various finishes identified by suffix
OPERATION
- Lever style handles
- Rotate hot side handle counterclockwise to open
and clockwise to close
- Rotate cold side handle clockwise to open and
counterclockwise to close
STANDARDS
- Third party certified to CSA B125, ASME A112.18.1M,
and all applicable requriements referenced therin
- ADA for lever handles
WARRANTY
- Lifetime limited warranty against leaks, drips and finish defects
to the original consumer purchaser
- 5 year warranty if used in commerical installations
™
M•pact System
Rev. 6/08
8-3/16"
(208mm)
3-7/8"
(98mm)
CRITICAL DIMENSIONS
2-15/16"
(74mm)
3-15/32"
(88mm)
(DO NOT SCALE)
FOR MORE INFORMATION CALL: 1-800-BUY-MOEN

Specifications

DIVINE™
Two-Handle Roman Tub Faucet Trim
Models: TS253 series
Valve: S923, S9203
10" (254mm) MIN
CENTERS
SPOUT
ESCTUCHEON DIA.
2-25/32" (71mm)
5-15/16"
(151mm)
HANDLE
ESCUTCHEON DIA.
2-5/32" (55mm)
www.moen.com
